| US$4,500.00-6,500.00 | 1 Set (MOQ) |
| Gauge | 12G,14G,16G |
| Knitting width | 80inch, 100inch, 120inch optioned |
| Knitting function | Knitting miss, turk, transfer, pointel, intarsia, jacquard, apparent or hide shaping and other regular or irregular patterns |
| Knitting system | Double carriage with two system |
| Knitting speed | Max 1.6m/s |
| Stitch density | Controlled by stepping motor, 32 section stitch selectable adjustable scope supported by subdivision technology. 0-650, the stitch of the knitwear can be accurately controlled. |
| Dynamic stitch | Various density changes and controls can be carried out in the same line. |
| Racking | Controlled by sevro-motor racking within 2 inches and with fine adjusting function. |
| Takedown roller | Programmed instruction controlled by stepping motor, 32levels selection adjustable range:0-100. |
| Transfer | Simultaneous transfer, front or back, independent of carriage direction. Split stitch possible without exchanging yarn carriers. |
| Sinker system | controlled by stepping motor, adjustable to different knitwear, up to be various results of shaping and patterns. |
| Needle selection | Advanced encoder reading pin. 8-stage selecting needle setup composed of special electromagnet is regarded as efficient full width jacquard needle selector. |
| Yam feed roller | Prevention coiling device yam feed roller, Electroplating ceramic roller, effective anti static. |
| Yam ariers | The new design of the color change device(lever principle), to eliminate the yarn feeder does not take. 2 sets of yarns are equipped with rollers to reduce yam breakage. |
| Top tension | 24units. One-touch easy threading. Large knots cause machine stop. Small knots cause 0-9 courses at specified knot detection speed, then automatically resume at set speed. |
| Stop motion | Yarn break, large knot, fabric pileup, shock detection, piece count, Over-torque, program error, etc. |
| Drive system | Belt drive. AC servo motor. No lubrication necessary. |
| Protection system | Automatically alarm when yarn-breaking knots floating yarn rewind end of knitting, fail of racking needle breakage error programming occur also set up the safety auto-lock protect device. |
| Needle detector | Knitting area alarm, non alarm outside weave area. Automatic reset |
