| Main dimension | L | 7650±50 mm |
| W | 1720±20 mm |
| H(Includes cab) | 2120±30mm |
| Ground clearance | ≥220 mm |
| Wheel base | 3100mm |
| Machine weight and axle load | Unladen weight | 6300±300 kg |
| Rated loading weight | 6000kg |
| Full load weight | 12300±300 kg |
|
| Driving speed | Slow Gear | 6.5±0.6 km/h |
| Fast Gear | 14±1.4 km/h |
| Gradeability | Climbing ability | ≥25% |
| Main Configuration |
| Engine | Manufacturer | Cummins |
| Structural features | Water cooled diesel engine |
| Maximum power | 96kW/2500rpm |
| Maximum torque | 520Nm / 1600rpm |
| Air intake system | Dry type air filter |
| Exhaust system | ECS Exhaust gas purification catalytic/muffler |
| Starting device power/volt | 5.5kW / 24V |
| Alternator Volts/Amps | 24V /110A |
| Emissions | National 4 |
| Drive axle | Trans-axle (front, rear) | \ |
| Structural features | Rigid trans-axle with standard differential and planetary reduction |
|
| Tyre | Tire | 250-15RG20 |
| Size | 740X246 |
| Inflation pressure | 4.9bar |
| Steering hydraulic system | Structural features | Central articulated, hydraulic power steering |
| Steering angle | ± 40º |
| Turning radius | Outer≤5500mm |
|
| System Flow | 85L/min |
| System pressure | 14MPa |
| Steering cylinder | 2PCS |
|
| Brake hydraulic system | Service brake/parking brake | Service brake: dual-axle independent hydraulic-assisted dual-circuit oil-immersed multi-disc brake |
| Parking brake: spring brake, hydraulic release, fail-safe parking brake. |
| Electrical System | Operating Voltage | 24V |
| Headlight | 2×45W |
| Rear light | 2×45W |
| Roof signal warning light | 1PCS |
|
| Cab | Driving seat | Elastic soft seat cushion, adjustable forward and backward |
| Seat | Speed hour meter, oil pressure gauge, brake pressure gauge, brake pressure warning light, oil pressure warning light, engine temperature warning light, Murphy meter. |
| Meter | Automatic fire extinguishing system plus handheld fire extinguisher |
| Optional | Automatic fire extinguishing system | Whole vehicle automatic lubrication system |
| Automatic lubrication system | Elastic soft seat cushion, adjustable forward and backward |
