US$195,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Refining Method
Physical Refining
Function
Degumming, Decolorization,
Function 2
Deacidification, and Deodorization.
Transport Package
Wrapping Film
Production Capacity
120 Units Per Year
Product Description
15tons Palm red oil impurity removal machine palm kernel oil processing machines Product Description
Main process:Hydration degumming, Neutralization deacidification, Adsorption decolorization, Filtration, Distillation
deacidification deodorization. Main equipment and use:
1, bleaching section using two automatic slag filter, Improve the continuity of the process.
2, deacidification deodorization tower, Use physical methods deacidification, deodorization, Reduce the refined oil losses.
3, oil and oil heat exchanger, high energy saving and high efficiency.
4, while using heat conduction oil stove and steam boiler, Improving oil yield and refined oil quality.
Product Parameters
Processing capacity | 3T/D | 5T/D | 10T/D | 15T/D | 20T/D | 30T/D | 50T/D | 100T/D |
Functional configuration | Intermittent degumming, continuous decolorization (or intermittent decolorization), continuous deacidification and deodorization. |
Equipment configuration | 2 refining tanks, 1 decolorization tower (or decolorization tank), 1 automatic feeding system for clay, 1 filtration system for clay, 1 deacidification and deodorization tower, 1 fatty acid recovery tower, 1 three-level Roots vacuum system, and 1 electrical control system (or PLC system). |
Equipment material | All SS304 stainless steel materials and carbon steel materials (the acid and odor removal part is SS304 stainless steel). Excluding platforms and auxiliary equipment. |
Installation Instructions
Semi-continuous refining equipment features:
1, Suitable for small enterprises.
2, Convenient a variety of oil mutual switching, which will help expand the business user.
3, The independent refining stage design, in favor of future expansion of production scale.
4, Low cost, energy saving, high standards of refined oil.
5,Can be used ordinary electric control and PLC control.
Recommended options:
Physical refining process, with economic, efficient and easy to operate, energy saving and other advantages.
Detailed Photos
