Plastic Recycling Pelletizers Melt Filter

Product Description

Plastic recycling pelletizer melt filter
Specification
1, base material is 38CrMoAlA
2, nitrided or chroming treatment
3, no material leakage
Technical data
1)The main body of the screen changer
Raw material:alloy steel(38CrMoAlA)
Surface treatment:Nitriding treatment
Depth of Nitrated Layer: 0.40-0.70mm
Nitrided hardness:950-1050Hv
Fragility of nitration: Less than grade 1

Flow channel treatment: chrome plated
Depth of chromium-plating:0.05-0.1mm
Hardness of surface after chromium-plating:HV>=950HV

2)Drive system:Hydraulic unit:
Hydraulic unit with accumulator
3)Control system
Electrical controlling system: warnning device,pressure and temperature transducer, are included. This part is optional for the customers.
Finished products
Application fields
1,Applicable to the production of various thermoplastic, chemical fiber, rubber, colossal, adhesive, coating and finishing materials alike, mainly used for filtration of the material mixture.
2,Such as blowmolding machines, film blowing machines, GRP processing machinery, granulators, Styrofoam machines, extrusion machines, plastic product making machines
Application case
Packaging
Commissioning
We provide the operation manual for customers to gudie to install the screen changer, and at the requirement of user, salers should send technician to install and commissioning the die at site of Buyers, expenses of the trip should be borne by Buyers.

After-sales service
12 months with proper operation by user, all the spare parts shall be replaced free of charge under guarantee period, fee for transportation and packing will be borne by users.

Type	Screen D&A		overall dimension(mm)				Heating power (KW)	Output (kg/h)
	(mm)	(CM²)	L	W	H	L1
GM_SSP-70	Φ70	38	200	170	240	820	3.5/5.8	80-200
GM_SSP-100	Φ100	78	220	185	280	930	4.5/6.8	150-350
GM_SSP-120	Φ120	113	260	205	320	1010	5.2/7.2	220-350
GM_SSP-150	Φ150	176	300	235	360	1140	6.5/8.5	350-800
GM_SSP-180	Φ180	254	320	245	360	1200	7.6/9.5	550-1250
GM_SSP-200	Φ200	314	360	280	420	1300	8.5/11	650-1500
GM_SSP-250	Φ250	490	450	300	430	1520	9.5/12	800-2500
GM_SSP-300	Φ300	706	520	380	500	1660	11.5/15.5	1200-3500
GM_SSP-320	Φ320	803	560	400	560	1700	13/17.5	1500-4000
Remark: As the above specification is subject to change without prior notice

---
