Product Details
Product Description
Product Description
Palm oil making machine( / ) is an important equipment to get crude palm oil. There are mainly six steps of palm oil production: raw material reception, sterilization, threshing, digesting & pressing, oil clarification and kernel recovery. The palm oil making machine has the advantage of energy-saving and low cost.
Production capacity of oil making machine :
1. 1-2-3-5TPH small palm oil making machine
2. 15-30-45-60-80-120TPH palm oil making machine;
1.Raw material reception: as for the first step of palm oil machine, collecting the FFB and convey by trucks, then pour the fluster into the discharge door after weighed by ground weigher . Start the control valve to open the gate of the discharge door, then the palm fruits will fall into the fruit basket car or conveyor.
2.Sterilizing:FFB are airtight sterilized in sterilizer, injecting direct steam (the pressure is 300KPa) to heat 60mins. The purpose is to prevent enzymes breaking down, avoiding FFA in oil further increasing. Meanwhile, the temperature will make the fruits soften, it is easy for threshing and the follow-up palm oil press production machine, it is also reducing the damaged kernel.
3.Threshing:the purpose of threshing is to separate the palm fruit from the FFB. The drum type thresher is the usual palm oil production machine (/) to separate the fruit. The separated oil palm fruit is sent into the pressing section. Empty fruit bunch be ejected to the yard as slipcover or burning in the locale as fertilizer.
4.Digesting&pressing:the purpose of digester is to separate the pulp and nut and crush the palm pulp. At the same time, the direct steam is used to adjust the water content and temperature in the crasher. After above processing of palm oil press production machine, the palm pulp become soft and cell is broken. Then it is sent to continuous screw press. After pressing by the palm oil press production machine, oil palm fruit is divided into two parts: the mixture of oil, water and solid impurities, and the press cake (fiber and nut).
5.Oil clarification: crude palm oil first diluted with water washing, through settlement and filtration, the fiber material removed from the oil, and then carry out continuous settlement, the whole divided into two parts: oil and sediment. Oil by centrifugal separation and through vacuum drying pumped into the storage tank for storing; oil sediment by filtration and dirt oil separation, oil process second settlement, dirt oil mixture process clarification separation.
6.Kernel recovery: first kernel was released by the ripple mill. The broken mixture enters into broken mixture separation system; separation system adopts two stage separation and water separation. After separation, shell is sent to the warehouse for temporary storage, as boiler room fuel when necessary; the moisture content of separation kernel falls to below 7% through the hot air to dry. Dried kernel is sent to kernel storage warehouse for storing. This is the final section of palm oil press production machine.
Crude palm oil standard:
FFA :≦ 5 %
Moisture :≦0.1 %
Dirt:≦0.02 %
Then, if you have any questions about the crude palm oil processing process, palm oil making machine, welcome to contact us when you are feel free. And our engineer will give you a professional and feasibility program about the palm oil making machine.
