Paper Bowl Cup Forming Machine

Product Description

B600 Paper Bowl Making Machine
Machine Description
MG-B600 upgraded single turntable type low mold stroke paper bowl machine, achieves a faster bowl
making speed of 80pcs/min which benefits from the low mold stroke and the design of highly integrated working
station. Whole machine main transmission parts are equipped with automatic spray oil lubrication system to
reduce wear and tear. Meanwhile, it adopts open type intermittent cam system and helical grear transmission,
which makes up for the inherent insufficiency of jitter and unstable transmission of chain transmission and greatly
prolongs the service life of the machine and reduces the failures the failure rate of the machine. While ensuring
high accuracy, it guarantees the stability of the machine's operation, low noise and high production capacity.
Machine Details
Technical Specification

Model	MG-B600
Bowls Specifications	20-50oz
Paper Specfications	150-350GSM single/double PE coated paper
Production Capacity	60-80pcs/min
Voltage	220V/380V 50HZ
Total Power	9KW
Total Weight	3000KG
Dimensions	2180*1400*1700mm(L*W*H)
Shipping Details	By sea/air transportation according to customer need
Paper Bowl Usage	Salad bowls, ice cream bowls, soup bowls, noodle bowls, takeaway bowls
Optional Equipmen	Paper cup machinery,die cutting machine,paper cup forming machine,cup top flatten machine and other products.
Customization	Almost all of our paper container forming machines can be modified and customized for Paper cups and Paper bowls. Please let us know your cup/bowl specifications and any of the other requirements, we will offer the professional solution to you.

Samples
Pre-sales and After-sales Service
Pre-sales service a.Provide products and related consultation. b.Free provision of paper cup samples (excluding freight). c.Customers can visit the factory in person to visit the machine. After-sales service: a.Paper cup machine warranty: 1 year b.We can dispatch technologists to buyer's factory, guiding installation, adjustment for a period. c.We supply the consumable spare parts for free for one year use.
FAQ
1. What products can be made by your machines?
Tea cups, coffee cups, ice cream cups, noodle bowl, salad bowl, KFC bucket etc.
Almost all the regular or irregular paper containers for fast food and drinks

2. What volume of the cup/bowl/bucket that you can make?
From 2-190OZ, about 50-5000ml

3. Are you a source manufacturer?
Yes, any of the factory visit tour appointments at any time are acceptable and warmly welcomed

4. What about the payment term?
Usually 30%T/T in advance, 70% Balance before shipping

5. What should I let you know before getting a relatively accurate quotation?
--Sample pictures
--Specifications of cups (Top diameter, Bottom diameter, Height)
Draft is the best if possible.

--GSM of single/double PE coated paper
Warmly welcome to contact us
FOR more details and professional 1-to-1 service
