| Specifications | | MY1224 | MY1230 |
| Table Size (LxW) | | 600x300mm | 750x300mm |
| Max movement of working table (LxW) | | 630x320mm | 780x320mm |
| T-Slot number×width | | 1x14mm | 1x14mm |
| Max distance from spindle center to table surface | | 520mm | 520mm |
| Wheel size (Outer diameter x Width x Inner diameter) | | 300x30x76.2mm | 300x30x76.2mm |
| Wheel speed | 50HZ | 1450r/min | 1450r/min |
| 60HZ | 1680r/min | 1680r/min |
| Longitudinal speed of working table | 3-20m/min | 3-20m/min |
| Vertical(up and down) feed on handwheel | Per revolution | 2mm | 2mm |
| Per graduation | 0.01mm | 0.01mm |
| Speed of vertical feed | | 360mm/min | 360mm/min |
| Cross feed(front and rear) on handwheel | Per revolution | 4mm | 4mm |
| Per graduation | 0.02mm | 0.02mm |
| Spindle motor | | 2.2KW | 2.2KW |
| Coolant pump motor | 40W | 40W |
| Lifting motor | | 120W | 120W |
| Hydraulic motor | | 2.2KW | 2.2KW |
| Working pressure | 4Mpa | 4Mpa |
| Oil tank capacity | 100L | 100L |
| Max flow | | 20L/min | 20L/min |
| The parallelism of working surface to base level | 300:0.005mm | 300:0.005mm |
| Surface roughness | Ra0.32μm | Ra0.32μm |
| N.W./G.W. | | 1400/1530kg | 1450/1550kg |
| Packing size | | 200x164x202cm | 200x164x202cm |
