Product Details
Product Description
Product Description
PRODUCT FEATURE
The 2YJ8x10 articulated three-drum static roller has a large unit linear load. It is mainly used for the compaction of pavement and foundation of gravel, crushed stone, asphalt concrete, coal slag, stone and other materials, which is the ideal compaction equipment for railway, highway, airport, port, dam and industrial construction site.
PARAMETERS
Operating mass
| kg
| 8000/10000
|
Front linear load
| N/cm
| 242/303
|
Rear linear load
| N/cm
| 343/429
|
1st gear
|
| 2.62
|
2nd gear
|
| 5.18
|
3rd gear
|
| 10.3
|
Grade ability
| %
| 20
|
Turning speed
| mm
| 5050/6450
|
Overall dimension
| mm
| 4400*1770*2620
|
Wheelbase
| mm
| 3220
|
Ground clearance
| mm
| 240
|
Diesel power/model
| Kw
| 36.8/Xinchai 4D32T31/502
|
Water tank capacity
| L
| 435
|
This product is continuously improved with technological progress. The difference between the above listed parameters and structural characteristics and the actual product shall prevail in the actual product.
>>
