Honeywell Analytics XNX Universal Transmitter XNX-AMAV-MHIF1
XNX-AMAV-MHIF1 XNX Universal Transmitter, ATEX M25 AL MDBS HRT MPD IR LEL by Honeywell Analytics
XNX Universal Transmitter, ATEX M25 AL FF HRT FOR TOX/O2 SNSRThe XNX Universal Transmitter, now with HART EDDL, marks a new turn in gas detection from Honeywell Analytics. It supports the widest range of sensors on a common platform and offers a modular choice of inputs and outputs.
XNX is designed for flexible integration, simple installation, user-friendly operation and straight-forward maintenance. It is ideal for use with a range of gas monitoring controllers or industry standard PLCs. The introduction of our HART Enhanced Device Descriptor Language (EDDL) software provides users with an at-a-glance indication of the health of their gas detectors in the field.
Bringing together the best solutions in gas detection
Electrochemical
Proven electrochemical sensing technology
Surecell™ electrochemical cells are ideal for hot and humid environments
Long life sensing cells (typical >2 years)
Patented 'Reflex' sensing element verification diagnostics
Sensor recognition software auto configures transmitter
Plug and play factory configured sensors
Intrinsically safe sensor connection permits hot swap, reducing down time
Please contact me get more information
Email:Mia@cwlyautomation.com
VK/Whatsapp/Telegram:+8613667120925
Website:
Catalytic Bead
Supports Honeywell Analytics 705, 705HT, Sensepoint, Sensepoint HT and MPD sensors
Fast response to wide range of hydrocarbons and flammables
Infrared (Open Path IR, Point IR, IR Cell)
Supports Honeywell Analytics Searchline Excel, Searchpoint Optima Plus
Failsafe operation
Fast speed of response
Reduced routine maintenance
Immune to catalytic poisons
Long operating life
Works in inert atmospheres
High performance
Flammable gas detection 0 to 100% LFL/LEL
Point IR with heated optics provides immunity to poisoning and no hidden faults
Open-path IR flammable gas detection in LEL-m measurement
Electrochemical cell offers toxic gas detection in ppm
IR cell provides CO2 and combustible gas monitoring
Robust and reliable operation in explosive areas and harsh environments
Flexible Operation
3 versions - supports (Catalytic Bead and IR Cell), Electrochemical Cell and IR (point and open-path) gas detection
Multi-Purpose Detector (MPD) with field serviceable mV, Catalytic bead and IR Cell capability
4-20mA with HART® as standard
HART Enhanced Device Description Language (EDDL) software*
Multiple communications options include up to 3 relays, MODBUS® and FOUNDATION® H1 Fieldbus
Optional local IS port for handheld HART configurator
Easy to Use
Large, backlit, easy-to-view LCD display offers multisensory indicators (visual icons, colored buttons, text, etc.) to display gas and sensor readings
User interface supported by 8 selectable languages (English, Spanish, German, Italian, Portuguese, French, Russian, Chinese)
Self-test and fault indication features
Non-intrusive, one-man operation
Quick calibration with auto-inhibit
Easy to Install
3 or 4 wire operation, source, sink or isolated
Simple plug-in sensors and replaceable cells
NEMA 4X IP66 rated for rugged indoor/outdoor use
Five conduit entries for ease of installation
Cost Effective
Minimal training required
One-man operation
Plug-in sensor replacement
All necessary accessories included
Please contact me get more information
Email:Mia@cwlyautomation.com
VK/Whatsapp/Telegram:+8613667120925
Website:
Other EC Sensors
HCl Hydrogen chloride XNXXSR1SS
H2S (Low) Hydrogen sulfide XNXXSH3SS
SO2 Sulfur dioxide XNXXSS
SO2(High) Sulfur dioxide XNXXSS2SS
NH3 Ammonia XNXXSA1SS
NH3(High) Ammonia XNXXSA2SS
Cl2 2 Chlorine XNXXSL2SS
(High)2 Chlorine XNXXSL1SS4
ClO2 2 Chlorine dioxide XNXXSX1SS
monoxide XNXXSM1SS
NO2 Nitrogen dioxide XNXXSN1SS
H2 Hydrogen XNXXSG1SS
H2(High) Hydrogen XNXXSG2SS
HF2 Hydrogen fluoride XNXXSF1SS
PH3 Phosphine XNXXSP1SS
HCN Hydrogen cyanide XNXXSY1SS
F2 Fluorine XNXXSU1SS
O3 Ozone XNXXSZ1SS
EtO Ethylene oxide XNXXSE1SS
>>
