Three Axies 250CNC Customizable CNC Grinding Machine for Unique Projects

Product Description

250/2550CNC Surface Grinding MachineThree Axies 250CNC Multifunction Grinding Machine Tool
We are committed to a policy of relentless enhancement of all our offerings. Therefore, we reserve the right to make adjustments to specifications, mechanics, or designs at any time without prior notice or obligation.

	parameter	unit	CNC-250	CNC-2550
general picture	Table size (x*y)	mm	200×500	250*500
	X axis travel	mm	580	580
	Y axis travel	mm	230	280
	Max center of wheel to table	mm	380	380
	Maximum load	kg	200	200
Table	Table T cell specification	mm×N	14×1	14×1
	Table speed	m/min	0-25	0-25
Y axis	Minimum feed	mm	0.001	0.001
	Single feed		0.1~10	0.1~10
	Fast moving speed	mm/min	0~1200	0~1200
Z axis	Minimum feed	mm	0.001/0.01	0.001/0.01
	Fast moving speed	mm/min	0~800	0~800
grinding	grinding wheel size max	mm	Φ200×Φ31.75×19
	grinding wheel speed	R.P.M	0~3600	0~3600
motor	spindle motor	HXP	2×2	2×2
	the Z axis motor	W	750	750
	the Y axis motor	W	750	750
	the X axis motor	W	1500	1500
	cooling motor	W	90	90
Size	height of machine	mm	2000	2000
	floor space	mm	2000×1350	2000×1450
	weight(about)	kg	1450	1550

Cheng Yu Machinery Technology Co., Ltd. was established in Dongguan City, Guangdong Province, and draws from an impressive 30 years of Taiwanese grinding machine manufacturing expertise, backed by a wealth of technical personnel and accumulated technological mastery. As CNC machine tools experience rapid growth, the industry is trending towards high-speed, precision, multifunctionality, intelligence, open architecture, parallel drive systems, network connectivity, and environmentally friendly practices. Dongguan Chengyu Machinery Technology Co., Ltd. specializes in the production and processing of machine tools and accessories, guided by our 'technology, innovation, reliability' philosophy and a 'meticulous' approach to quality. We strive to deliver exceptional products and customer service by studying customer processes, technology, production needs, and quality requirements. Using advanced design and production techniques, we continually enhance product applicability, expand the CNC industry's reach, and position products with high automation, precision, and quality. Our complete and scientific quality management system, first-class equipment, and exceptional technology support this mission. Chengyu Machinery, in response to market demands, excels in the design and creation of high-precision CNC grinding machines, including surface grinders, CNC forming machines, four-axis punch grinders, vertical slider grinders, and gantry rail grinders. We also design industrial robots, automated production lines, and integrated applications. Below is a concise introduction to our CNC grinding machine series: I. HS series 618 / 250 / 3060 / 4080 / 40100 (available in servo type or hydraulic type) Processing capabilities: Surface grinding, grooving Features a patented hydraulic control system (hydraulic type) Functions: Comes with a grinding program for flat surfaces and groove cutting. Feeding options: Offers front/back and left/right feed selection, with feed mode memory for each grinding program. Includes grinding wheel overload protection with an automatic shutdown feature. II. Available in servo type or hydraulic type Processing capabilities: Surface grinding, grooving, and combined scheduling Features a patented hydraulic control system (hydraulic type) Functions: Includes diverse grinding programs for surface, groove, sole, side, unequal distance, and unequal depth displacement grinding. Grinding wheel dressing: Automatically performs bottom plane dressing according to set rough/fine grinding times and amounts, with automatic dressing and compensation during the grinding cycle. Feeding options: Offers front/back and left/right feed selection, with feed mode memory for each grinding program. Capable of equidistant grooving as well as non-equidistant, unequal grooving. 3. Four-axis CNC grinding machines, available in horizontal and vertical configurations. Processing types: Accommodates arbitrary equal division and skipping tooth processing. For waist circle: Enter AB size. Triangle fillet: Enter inscribed circle size B and fillet size R. Quadrilateral fillet: Enter side length A, side length B, and fillet size R. Eccentric circle: Enter eccentricity and starting/ending diameters. Circle: Simply input starting and ending diameters to achieve precision machining. Arc: Define the arc size and rotation angle to sculpt with pinpoint accuracy. Step Difference: Easily handle rotation profiles and more with our user-friendly interface. Save your processing schedule as a file for seamless access and effortless execution next time.

---
