| US$15,000.00 | 1 Set (MOQ) |
| Model | 4LZ-2.0 |
| Cutting width | 2000mm |
| Working capacity | 0.4 hec/h |
| Fuel consumption | 6-8L/h |
| engine horsepower | 70HP(52KW) |
| Weigh (kg) | 2550 |
| Track | 350mm*90mm*46 |
| Dimensions at work, LxWxH(mm) | 5240x2690x2675 |
| Total losses (%) | Rice≤3.0 ,Wheat≤1.5 |
| lmpurity rate (%) | ≤2.0 |
| Breakage rate (%) | ≤1.5 |
| Reliability (%) | ≥93 |
| Feed rate (kg/s) | 2.0 |
| Ground pressure (Kpa) | ≤24 |
| Min.ground clearance (mm) | ≥200 |
| grain Tank | 0.3m3 (storage 150kg rice) |
| Cleaning type | Double sieves + blower + re-thresher |
| Grain unloading method | Sacked & Auto unloading |
| Shipment | 1set/20'FCL,3sets/40'HQ |
| ltem\ Model | 4LZ-3.0 |
| Cutting width | 2580mm |
| Working capacity | 0.47 hec/h |
| Fuel consumption | 8-10L/h |
| engine horsepower | 60KW(82HP) |
| Weigh(kg) | 3200 |
| Track | 400mm*90mm*48 |
| Dimensions at work,LxWxH(mm) | 5280x2960x3000 |
| Total losses(%) | Rice≤3.0 ,Wheat≤1.5 |
| lmpurity rate(% | ≤2.0 |
| Breakage rate(%) | ≤1.5 |
| Reliability(%) | ≥93 |
| Feed rate(kg/s) | 3.0 |
| Ground pressure(kpa) | ≤24 |
| Min.ground clearance(mm) | ≥200 |
| grain Tank | 1.3m3 (storage 700kg rice) |
| Cleaning type | Double sieves + blower + re-thresher |
| Grain unloading method | Sacked & Auto unloading |
| Shipment | 2sets/40'HQ |
| Feeding Capacity (kg/s) | 4 | ||
| Work Dimension L*W*H (mm) | 4900*2890*2700 | ||
| Weight (kg) | 2900 | ||
| Cabin/Sun Shade | Sun Shade | ||
| Engine Part | Model No. | Changchai 4L88 | |
| Power/Speed (hp/rpm) | 88/2700 | ||
| Fuel | Light Diesel Oil | ||
| Fuel Capacity (L) | 160 | ||
| Fuel Consumption (kg/hm2) | 12~30 | ||
| Start | Motor Starter | ||
| Gear Box | ZKB85 made by WORLD Factory. | ||
| HST | 45CC HST Imported from South Korea. | ||
| Walking Part | Rubber Track | Length of Ground Contact (mm) | 1700 |
| Center Distance (mm) | 1160 | ||
| Size (mm) | 500*90*51 | ||
| Average Contact Pressure (kpa) | ≤20Kpa | ||
| Min. Ground Clearance (mm) | 300 | ||
| Gear Shifts | Variable Sun-transmission 3 Shifts | ||
| Walk Speed (Km/Hour) | Low: 0~1.85 Medium: 0~6.5 High: 0~9 | ||
| Theoretical Work Speed (Km/Hour) | 0.9-6.5 | ||
| Harvesting Unit | Grain Lifter | Divider | |
| Working Width (mm) | 2200 | ||
| Reel Bat | Dia. × Length (mm) | 900×2028 | |
| Gearshift Method | Constant Speed | ||
| Adjusting Means | Hydraulic | ||
| Stubble Height[Lift] (mm) | 25cm or above | ||
| Threshing & Harvesting Unit | Threshing Mode | Axial Flow Type, Bullet Rotor | |
| Threshing Rotor | Type of Threshing | Beat Bar | |
| Dia. ×Length (mm) | 620*2050 | ||
| Rotating Speed (rpm) | 662/732 | ||
| Fan | Diameter | 400 | |
| Separating Type | Vibrating Sieves + Air Blow | ||
| Area of Sieves (Lowe and Upper Sieves) (m2) | 1.645 | ||
| Grain-unload Unit | Grain Tank Capacity (m3) | 1.4 | |
| Grain Discharging Type | 360 Degree Rotary Discharging Pipe | ||
| Alarm Units | Water Temperature, Battery, Oil, Grain Tank, Jam of 2# Auger | ||
| Work Efficiency (hm2/h) | 0.4~0.7 | ||
| Crops | Rice, Wheat | ||
| Total Loss | Less than 2.5% | ||
| Breakage | Less than 1.5% | ||
| Impurity | Less than 1.5% | ||
