Waterproof 12V AC DC LED Transformer Converter 120W 10A 24V Switching Power Supply with RoHS FCC CE

Product Description

Product Description Waterproof 12V AC to DC LED transformer Converter 120W 10A Switching Power Supply RoHS Features:
1. Universal Input 180 ~ 264 VAC 2. Output : 120W 12V 10A (MAX) 3. Low Power Consumption 4. Approvals: FCC/ CE 5. Protections: Over Load/ Over Voltage/Short Circuit 6. 100% Full Load Burn-in Test 7. 1 Years Warranty
Package included:
1 x Power Supply (Power cord is NOT included.)
Detailed Photos
Product Parameters

Model NO.	Output	item size/mm	W./g	Carton size/mm	Package/CTNS	G.W./KG
HY-60FC-12V	12V/5A/60W	120x74x42	180	490*265*340	80pcs	15.00
HY-120FC-12V	12V/10A/120W	145x74x42	230	490*305*340	80pcs	21.20
HY-150FC-12V	12V/16A/200W	185x74x42	295	485*390*257	60pcs	13.60
HY-200FC-12V	12V/16.7A/200W	166x94x50	320	440*290*260	60pcs	22.50
HY-350FC-5V	5V/70A/350W	191x117x50	442	612*460*255	50pcs	23.50
HY-400FC-12V	12V/33.3A/400W		420	612*460*255		23.50
HY-400FEC-12V	12V/33.3A/400W		420	612*460*255		23.50
HY-400FC-24V	24V/16.7A/400W		420	612*460*255		23.50
HY-400FC-II-12V	12V/33.3A/400W	181x117x50	385	546*386*390	60pcs	25.00

Ripple and Noise	120mVp-p	200mVp-p	120mVp-p
Voltage regulation range	11.5-12.5V	23.5-24.5V	11.5-12.5V
Voltage stabilization accuracy	±2%	±1.5%	±2%
Line Regulation	±0.5%	±0.5%	±0.5%
Load Regulation	±1.5%	±1%	±1.5%
RisingTime	2000ms,30ms@220Vac
Hold up Time	10m5 @220Vae, at full load
Voltage Range	180~264Vac200-380vdc
Frequency Range	50~60HZ
Efficiency	90%
AC Current	1.94A@220Vac
Surge Current	50A G220Vac Cold air dynamics
Leakage Current	<0.75mA@220Vac
Overload	110%~150% of rated output power, protection mode; Hiccup mode, can be visually restored after removing abnormal conditions
Over voltage	110%~135% of rated output power, Protection mode; Hiccup mode, Can be visually restored after removing abnormal conditions
Short circuit	Protection mode; Hiccup mode, can be visually restored after removing abnormal conditions,Can be short circuited for a long time
operation temperature	-20ºC-,50ºC
Operating Humidity	20%~90%RH, No condensation
Storage temperature ,humidity	-40ºC.85ºC,10%~95%RH, No condensation

If there have any mode meets your requirement,pls contact us get more detail
https://huayipower.en.made-in-china.com/product-list-1.html

Item	Output					Item size	Weight	PC/CTNS
	5V	12V	24V	30V	36V	(MM)	(KG)	(PCS)
HY-400FB		33.3A	16.6A	13.3A	11.2A	193*117*50	0.47	50
HY-350FB	70A					193*117*50	0.49	50
HY-400FA		33.3A	16.6A			207*118*50	0.62	40
HY-400FAC		33.3A	16.7A			207*118*50	0.62	40
HY-400FA-II		33.3A	16.7A			179*109*51	0.54	40
HY-400GB		33A	16.6A			204*117*50	0.47	40
HY-600FA		50A	25A			217*118*50	0.85	30
HY-400FC		33.3A	16.7A			191*117*50	0.42	50
HY-400FEC		33.3A				191*117*50	0.42	50
HY-350FC	70A					191*117*50	0.42	50
HY-400FC-II		33.3A				181*117*50	0.39	60
HY-200FC		16.7A				166*94*50	0.32	60
HY-150FC		12A				185*74*42	0.29	60
HY-120FC		10A				145*74*42	0.23	80
HY-60FC		5A				120*74*42	0.18	80
HY-300TF		25A				191*117*50	0.42	60
HY-300TBS		25A				191*117*50	0.42	60
HY-300TBD		25A				166*94*50	0.32	60

Notes
1. Unless otherwise specified, all specification parameters are measured at an input of 220Vac, rated negative, and 25 "C ambient temperature
2. Ripple and noise Runwu method: Use a 12 twisted pair cable, with terminals connected in parallel with 0.1UF and 47uF capacitors, and measure the ripple at a bandwidth of 20MHz
3. Pressure accuracy: including setting error, linear adjustment word, and negative adjustment rate
4. Linear adjustment rate measurement method: Under a certain load, test from low input voltage to high input voltage,
5. Test method for load adjustment rate: from 0 to 100% rated load
6. The startup time is measured in a cold start state, and rapid and frequent shutdowns may increase the startup time
Company Profile ABOUT US & FACTORY Shenzhen Huayi Power, 200 staff, Shenzhen headquater and Hunan factory, have specialized in LED power supply and drivers since 2021. Our products cover Rainproof / outdoor / indoor / engineering power supply and drivers, power adapter, electronic components, etc. Adhere to independent innovation, stable quality and low cost, our company has obtained a fast growth. Good product, professional solution and efficient service, are making us to be the trusted partners with cutomers coming from Ameica, Europe, Japan, domestic market, etc.
Certifications
Packaging & Shipping 80box/CTNS
We use standard shipping cardboard boxes to package your goods and take absolute safety measures. If you have packaging requirements, please let us know!

FAQ Q: How many Voltage you can supply?
A: 5V,12V,24V,30V,36V,(Depend on items).
Q: Do you have any MOQ limited for the order?
A:Yes.our MOQ is 1000pcs.
Q:Do you offer guarantee for the products?
A:Of courser,we support 1 year guarantee .
Q: How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or EMS. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q: How to deal with the faulty?
A: Firstly, our products are produced in strict quality control system and the defective rate will be less. Secondly, during the guarantee period,we will send new product with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.

---
