Chemical Equipment Machinery Glass Lined Chemical Reactor FF220-10000L

Product Description

Product specification: 3000L-20000L
Product standard: GB25025-2010, GB/T 150-2011
Product use: This glass-lined reactor is mainly used for large-scale chemical and pharmaceutical experiments. The glass-lined reactor is also suitable for precision conditions of large-scale production in chemical and pharmaceutical industries. Closed glass lined reactor is widely used in medium chemical, petroleum, medicine, pesticide, food, dyes and other industries, is the hydrolysis, neutralization, crystallization, mixing, emulsification selection equipment.

Series				FF Series
Basic Model				FF160		FF175				FF200						FF220				FF240		FF260		FF280			FF320		FF340
Normal Volume(L)				3000		5000		6300		8000			10000			10000		12500		16000		20000		25000			30000		40000
Actual Volume(L)				3755		5855		6822		9039			10100			11569		13583		16875		21697		27770			34550		45345
(MPa)		Body		0.4		0.4		0.4		0.4			0.4			0.4		0.4		0.4		0.4		0.4			0.4		0.4
		Jacket		0.6		0.6		0.6		0.6			0.6			0.6		0.6		0.6		0.6		0.6			0.6		0.6
Area of h.exch(m²)				9.3		13.3		15.4		18.1			19.4			20.2		23.7		27.4		28.4		40.6			44.15		54.46
Type of Agitator				Impeller
Agitator(r/min)				130		130		130		130			130			130		130		130		130		85			85		85
Type of Shaft Seal				212-95		212-95		212-95		212-110			212-130			212-130		212-130		212-130		212-130		212-140			212-160		212-160
Reducer(kw)				5.5		7.5		7.5		11			11			11		15		18.5		18.5		30			37		45
D1(mm)				1600		1750		1750		2000			2000			2200		2200		2400		2600		2800			3200		3400
D2(mm)				1750		1900		1900		2150			2150			2400		2400		2600		2800		3000			3400		3600
H1(mm)				195		195		195		230			217			230		230		230		250		250			290		290
H2(mm)				2280		2848		3250		3430			3690			3560		4090		4280		4641		5060			4900		5640
H3(mm)				1427		1467		1467		2170			2150			2210		2210		2304		2404		2733			2812		2937
H4(mm)				1180		1220		1220		1440			1410			1500		1500		1520		1580		1500			1750		1800
H5(mm)				205		200		250		330			300			295		295		325		300		300			300		300
H(mm)				4047		4658		5035		6166			6489			6383		6953		7235		7584		8063			8032		8887
d(mm)				800		850		850		1100			1100			1200		1200		1200		1300		1400			1600		1700
(mm)Centre Circe of Vent				1120		1200		1200		1500			1500			1600		1600		1700		1820		2000			2300		2400
Discharge Valve				DN125/80		DN125/80		DN125/80		DN150/100			DN150/100			DN150/100		DN150/100		DN150/100		DN150/100		DN150/100			DN150/100		DN150/100
(kg)Total Weight				2825		4025		4740		6665			6635			8631		9580		11933		14600		17815			20905		26065
Type of Supporting				Lug Support
(φmm) Centre Circle of Lug Supporting				1954 4-φ30		2152 4-φ30		2152 4-φ30		2407 4-φ30			1600 4-φ30			2708 4-φ36		2708 4-φ36		2868 4-φ36		3110 4-φ36		3385 4-φ36			3916 4-φ36		4118 4-φ36
Series	Shafthole		Manhole, Hand hole		Thermometer hole				Lens hole		Spare hole								Discharge hole		Nozzle hole							water, Gas inlet out nozzle
	G		M(H)		T1		T2		S,-		N1	N2		N3	N4		N5		B		P2		P3		P4	P5		P1		L-a
FF160	125		300×400		100				125		150	125		100	125				125											50
FF175	125		300×400		125				125		150	150		125	150				125									65		65
FF200	200		300×400		200				125		125	150		125	150		125		150									65		65
FF220	200		300×400		200		200		125		150	150		150	150		125		150									80		80
FF240	200		450		200		200		125		150	150		150	150		125		150									80		80
FF260	200		450		200		200		125		150	150		150	150		125		150		80		80		80			80		80
FF280	250		500		300		300		125		200	200		200	200		150		150		80		80		80	80		80		80
FF320	250		500		300		300		125		200	200		200	200		150		150		80		80		80	80		80		80
FF340	250		600		400		400		150		200	200		200	200		150		150		80		80		80	80		100		100

Closed glass lined reactor is a high silicon ceramic glaze sprayed on the surface of the steel container, metal surface composite material products after high temperature combustion process, glass lined reverse tank lid should be one of the tank. It has the dual advantages of glass stability and metal strength. It is an excellent corrosion resistant chemical equipment. It has corrosion resistance, impact resistance, smooth appearance, insulation, heat resistance, wear resistance and other reliable properties. Because the tank cover and tank body are completely closed and cannot be separated, the closed enamel reactor is suitable for the environment with higher pressure in the tank, which can avoid or reduce leakage; At the same time, due to the limitation of installation size, the mixing slurry in closed enamel reactor is not as large as that in open reactor. Closed glass lined reactor and open glass lined reactor are widely used in chemical, petroleum, medicine, pesticides, food, dyes and other industrial processes. It is an ideal equipment for hydrolysis, neutralization, crystallization, mixing and emulsification.

---
