Specification
| Overall weight(kg)
| 5600
|
L×W×H（mm）
| 6420x2054x2862
|
Rated bucket capacity(m3)
| 1.0
|
Rated load(kg)
| 2200
|
Max. dump height (mm)
| 3093
|
Bucket indicator
| Yes
|
Engine
| Model
| Changchai4G33
|
Type
| Vertical, In-line , Water cooling, four-stroke diesel engine
|
Rated power（kw）
| 70kw
|
Rated speed(r/min)
| 2400
|
Optional
| Cummins QSF2.8 EPA
|
Transmission system
| Model of torque converter
| YJ280
|
Gearbox type
| Fixed-spindle power shift
|
Gear shift
| 2 gears ahead,2 gear astern
|
Hydraulic system
| Working pressure
| 16Mpa
|
Boom lifting time
| 4.8s
|
Fuel tank capacity
| 95L
|
Steering system
| Type
| hydraulic steering
|
Min turning radius(mm)
| 4595
|
Tire
| Standard tires
| 16/70-20
|
Standard bucket
| Width (mm)
| 2100
|
