6000W off-Grid Solar Power Inverter with PWM Charge Controller for Solar System/Home

Product Description

H Series Inverter/Off-Grid Inverter with PWM Controller 6000W
Our H series solar inverter full-bridge pure sine wave output, low loss, is an efficient power frequency energy-saving transformer.
Built-in 30A/60A solar charge controller. Suitable for multiple scenarios: RV systems, Home off-grid systems, Base stations, Herdsmen, Islands, and Monitoring systems. Supports multiple communication interfaces for remote monitoring via RS232/mobile app/Wi-Fi/GPRS
Advantages and features
• Power frequency energy-saving transformer with full-bridge pure sine wave output, low loss and high efficiency
• Triple surge power with strong loading capability
• Power bypass and inverter output, optional UPS function
• Built-in 30A/60A solar charge controller
• Intelligent LCD+LED display shows system operation status
• Unattended duty-free function
• Support a variety of communication interface, remote monitoring via RS232/mobile App/Wi-Fi/GPRS
Product details

MODEL		HP2KW	HP3KW	HP4KW	HP5KW	HP6KW
TECHNICAL
BATTERY	Nominal voltage	12V/24Vdc	24/48VVdc		48V/96Vdc
	Charging voltage	10A - 25A
	Charging voltage	13.8Vdc for 12Vdc (*2 for 24Vdc, *4 for 48Vdc) battery
	Battery high voltage alarm	15Vdc for 12Vdc (*2 for 24Vdc, *4 for 48Vdc) battery
	Battery low voltage alarm	10.5Vdc for 12Vdc (*2 for 24Vdc, *4 for 48Vdc) battery
	Battery type	Lithium battery / gel (factory default)
INPUT	Voltage	L+N+PE, 110V/120Vac; 220V/230V/240Vac
	Voltage range	75V~135Vac for 110Vac grid; 145V~265Vac for 220Vac grid
	Frequency	50/60Hz (auto sensing)
OUTPUT	Output mode	Single phase, L+N+G
	Voltage	110V/120V; 220V/230V/240Vac
	Frequency	50/60Hz ±1% (in inverter mode)
	Surge power	6kVA	9kVA	12kVA	15kVA	18kVA
	Efficiency	89%	90%			89%
	Switch time	≤8ms
	Waveform	Pure sine wave
	Transfer time	<4ms (typical load)
	Protection	Overvoltage, undervoltage, overload, over temperature, surge, short circuit
	Display	LCD+LED
	Heat dissipation mode	Fan
	Communication (optional)	RS232 / RS485 / App / Wi-Fi
WORKING MODE	Grid prior	Priority is given to power grid, and transfers to battery inverter when power grid is abnormal
	Eco mode	The device automatically goes into sleep mode when the load is empty
	PV prior	PV first, and when PV is not enough, battery and grid complement each other
PV INPUT	MPPT optimal voltage	18~21Vdc for 12Vdc PV; 30~36Vdc for 24Vdc PV; 60~70Vdc for 48V PV
	Maximum charge current	30A/60A
	Maximum PV array power	12V/350W; 24V/720W; 48V/1440W for 30A MPPT;
		12V/720W; 24V/1440W; 48V/2880W for 60A MPPT
	Maximum PV array voltage	25Vdc for 12Vdc; 50Vdc for 24Vdc; 100Vdc for 48V
ENVIRONMENT	Humidity	0% ~ 95% relative humidity (non-condensing)
	Environmental temperature	-10 ~ 50°C
	Storage temperature	-15 ~ 60°C
PHYSICAL
Product dimensions (mm)		535x410x250mm		605x410x250mm
Gross Weight (kg)		8	9.5	10.5	11.5	12.5
