Product Description
Product Description
Product Description
AT235 Bench-top Wet Spinning Machine is special design for researching new material in the field of textile, macromolecule and other material. It consists of mixing tank, dosing pump, filter, spinneret, coagulating bath, drawing roller, heating bath, drawing roller, setting bath, drawing roller and winding.
Specification
Model
|
| AT235
|
|
Mixing tank
|
| 1L or customized, 316L stainless steel
|
|
Sample volume
|
| 200~ 600ml or customized
|
|
Vacuum pump
|
| 0.18kW
|
|
Dosing pump flow rate
|
| 0.66CC/rev
|
|
Dosing pump power
|
| 180W
|
|
Dosing pump reducer
|
| 1:60
|
|
Spinneret
|
| 1
|
|
Spinneret plate
|
| 100 holes, hole dia.: 0.07mm
Material: tantalum
|
|
The Whole line length
|
| 5000mm
|
|
Power supply
|
| 200V, 50Hz
|
|
Coagulating bath
|
|
|
|
Size
|
| 1000*160*160mm
|
|
Heating power
|
| 0.6kW
|
|
Material
|
| 316L stainless steel
|
|
Drawing roller
|
|
|
|
Material
|
| Nylon or 316L stainless steel
|
|
Size
|
| Ø50×80mm
|
|
Reducer
|
| 1:10
|
|
Motor power
|
| 25w
|
|
Roller speed
|
| 2~40m/min adjustable
|
|
Heating bath
|
|
|
|
Type
|
| non-contact
|
|
Length
|
| 400mm
|
|
Heating power
|
| 250W
|
|
Temp. range
|
| 20~150℃
|
|
Sensor
|
| PT100
|
|
Setting bath
|
|
|
|
Type
|
| non-contact
|
|
Length
|
| 800mm
|
|
Heating power
|
| 250W
|
|
Temp. range
|
| 20~150℃
|
|
Sensor
|
| PT100
|
|
Winder
|
|
|
|
Speed
|
| 2-40m/min
|
|
Size
|
| Ø50×80mm
|
|
Transverse displacement
|
| 55mm
|
|
Futures
★ 316l Stainless steel frame, durable and nice
★ Mini size, save space
★ It can simulate the whole process
★ Thermal system for mixing tank is selectable
★ Heating bath can adopt air heating or water heating, it's selectable.
★ The whole line adopt quick joint connecting, it's easy to assemble.
Related Products
AT206 Laboratory Ring Spinning Machine
| AT225 Laboratory Melt Spinning Machine
| AT247 Automatic Air-Jet Sample Loom
| AT241C Automatic Single Yarn Warping Machine
|
Our Company
History
Since 1982 with more than 20 years' experience
Warranty
Two Year Warranty for whole product
Training
Video and user manual for training
Onsite service
Installation and training service is available
Testing service
Free sample testing before order is available
Lead time
15 working days lead time for most product
