Main Features
● Adopt Xinchai diesel engine, good reliability, large reserves of torque, low fuel consumption, high economic efficiency;
● Double-function clutch,10 inches, high transmission capacity, reliable, comfortable manipulation;
● Gearbox using 4 × 3(1 +1) engaging sleeve, shuttle-type gearshift, there are 12 forward gears, 12 reverse gears, reasonable match between the gears, and have high efficiency;
● Independent power take off device, smooth transmission, large capacity, speed (540/760, 540/1000 r/min) for selection to meet the different operation requirements;
● Full hydraulic front wheels steering, independent oil circuit for steering system, manipulating flexible, reliable, and save energy;
● Adopt hydrostatic disc-type brakes, a large braking torque, the braking effect is good;
● Adopt high pressure type lifting device, reliable, easy maintenance, multi-hydraulic output can be optioned;
● Final transmission adopts planetary gear mechanism, compact structure, large reduction ratio;
● New streamlined appearance, generous, modern, fashion;
● Control levers can be mounted at side as optional, more convenient and comfortable.
| Tractor Model | 604 |
| Drive Type | 4X4 |
| Overall Dimension L×W×H(mm) | 3925×1728×2170 |
| Wheel base(mm) | 2010 |
| Front wheel tread(mm) | 1265 |
| Rear wheel tread(mm) | 1200--1500 (Common 1300) |
| Min. ground clearance(mm) | 375 |
| Min. steering radius | Unilateral brake(m) | 3.8 |
| Not unilateral brake(m) | 4.3 |
| Min. operating weight (KG) | 2565 |
| Gearbox gears number | 12F+12R |
| Speed | Forward(Kw/h) | 2.33-31.04 |
| Reverse(Kw/h) | 2.04-27.21 |
| Engine | Model | A4K41T60 |
| Rated power (Kw) | 44 |
| Rated speed (r/min) | 2300 |
| Tires spec. | Front tires | 8.3-24
14.9-28 |
| Rear tires |
| Steering Type | Full hydraulic front wheels steering |
| Max. lifting force( KN ) | 9.9 |
| PTO | Type | Rear-mounted, Semi-independent type |
| Speed (r/min) | 540/760 or 540/1000 |
| Power(Kw) | ≥37.4 |
| Control type of ploughing depth | Height control & flotation control |
| Max. traction force (KN) | 12.5 |
| Front / rear Ballast (KG) | 104/300 |
>>
