| olding Force | 617lbs (280kg±15%) |
| Operating Voltage | 12V/24V DC |
| Working current | 340mA |
| Operating temperature | *-25 ºC~60 ºC |
| Working humidity | 10%~90%RH |
| Way of unlock | Power on to lock(Fail safe) |
| Installation method | Hanging installation (Surface installation) |
| Door opening angle | 90° |
| Panel material | High strength aluminum alloy |
| Finish | Oxidation & brushed finishing |
| Signal feedback | no |
| Indicator light | Red LED |
| Magnetic size | 238*25*48 mm |
| Armature plate size | 182*38*12.5mm |
| Scope of application | Wooden door, Fireproof door, Glass door, Metal door |
| Service life | More than 500000 times |
| Weight | 1.9kg/PCS |
| Packing quantity (PCS/CTN) | 1 |
| Certifications | FCC/CE/REACH/ROHS |
