| Model Number | MSL06 | MSL08 | MSL10 | MSL12 | |
| Max platform height | mm | 6000 | 8000 | 10000 | 11800 |
| Max working height | mm | 8000 | 10000 | 12000 | 13800 |
| Load capacity | kg | 300 | 300 | 300 | 300 |
| Maximum height when closing (guardrail stands up) | mm | 2150 | 2275 | 2400 | 2525 |
| Maximum height when closing (guardrail removed) | mm | 1190 | 1315 | 1440 | 1565 |
| Total length | mm | 2400 | 2400 | 2400 | 2400 |
| Total width | mm | 1150 | 1150 | 1150 | 1150 |
| Platform size | mm | 2270x1150 | 2270x1150 | 2270x1150 | 2270x1150 |
| Extended platform Length | mm | 900 | 900 | 900 | 900 |
| Minimum ground clearance (closed state) | mm | 110 | 110 | 110 | 110 |
| Minimum ground clearance (lifting state) | mm | 20 | 20 | 20 | 20 |
| Wheelbase | mm | 1850 | 1850 | 1850 | 1850 |
| Minimum turning radius (inner wheel) | mm | 0 | 0 | 0 | 0 |
| Minimum turning radius (outer wheel) | mm | 2100 | 2100 | 2100 | 2100 |
| Machine moving speed (closed state) | km/h | 3.5 | 3.5 | 3.5 | 3.5 |
| Machine moving speed (lifting state) | km/h | 0.8 | 0.8 | 0.8 | 0.8 |
| Rise/fall speed | sec | 70/80 | 70/80 | 70/80 | 70/80 |
| Battery | V/Ah | 4x6/210 | 4x6/210 | 4x6/210 | 4x6/210 |
| charger | V/A | 24/25 | 24/25 | 24/25 | 24/25 |
| Maximum climbing ability | % | 20 | 20 | 20 | 20 |
| Working maximum allowable angle | / | 2-3° | 2-3° | 2-3° | 2-3° |
| Driven | / | Double front wheel | |||
| Hydraulic brake wheel | / | Double rear wheel | |||
| Wheel size | / | Φ381x127 | Φ381x127 | Φ381x127 | Φ381x127 |
| extended platform load capacity | kg | 113 | 113 | 113 | 100 |
| Net weight | kg | 1900 | 2080 | 2490 | 2760 |
