280s Fingerless Adsorption Single Facer with Material of Hard Chrome

Product Description

280S Fingerless Adsorption Single Facer with material of hard chrome
SF-280S fingerless type single facer
Structural features:
★pressure roller ¢ 284mm,surface grinding and chrome-plated;cylinder control and remove up and down, 45 carbon steel materials, quenching (with cushioning devices).
★pneumatic control glue to glue back, glue roller diameter ¢215mm,Engraved polished surface after a 36-line pit style textured machined chrome plated,after scraping the roller surface polished hard chrome plated.
★Corrugated roller, pressure roller materials provided by the Central Plains Steel,High on corrugating unilateral 0.15mm, 0.075mm high pressure roller unilateral. Plus stopper. ¢ 160mm cylinder with compression cylinder.
★preheat roll adopt seamless steel pipe production by tiangang ¢ 300mm,connecting with metal Hose
regular technical parameters:
1,effective width:1600mm
2,operation direction:left or right(determined in accordance with customer plant)
3,design speed:100m/min
4,temperature range:200-260ºC
5,corrugated flute:(UV type or UVV type)
roller diameters parameters:
1,diameter of corrugated roller: ¢280mm
2,diameter of pressure roller: ¢284mm
3,diameter of glue roller: ¢216mm
4,diameter of preheat roller: ¢320mm
powered motor parameters:
1,main drive motor:7.5Kw rated voltage:380V 50Hz Continuous (S1) working standard
2,suction motor:7.5Kw rated voltage:380V 50Hz Continuous (S1) working standard

---
