US$35,000.00-58,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Process Usage
Metal-Forming CNC Machine Tools
Movement Method
Contour Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
High-End CNC Machine Tools
Certification
CE, ISO 9001
Electric Turret Type
8/12
Weight
3300*2000*2100mm/5500kg
Max Swing Over Cross Slide
400mm
Transport Package
Customer Choice
Specification
3300*2000*2000mm/3600kg
Production Capacity
100 Piece/Year
Product Description
Product Description
| Specification | | TCK36A | TCK46A | TCK56A | TCK66A |
| Max swing over bed | mm | φ360 | φ460 | φ560 | φ660 |
| Max swing over cross slide | mm | φ140 | φ170 | φ360 | 400 |
| Distance between centers | mm | 300 | 350 | 500 | 600 |
| Max turning length | mm | 300 | 350 | 500 | 700 |
| Screw specifications | X | | 2510 | 3210 | 3212 | 4010 |
| Z | | 3210 | 3210 | 3212 | 4010 |
| Spindle hole | mm | φ48 | φ56 | φ65 | Φ85 |
| Bar capacity | mm | φ41 | 45 | φ50 | Φ75 |
| Spindle nose | | A2-5 | A2-5 | A2-6 | A2-8 |
| Spindle speed | rpm | 4000 | 3500 | 3500 | 2800 |
| Tailstock diameter | mm | φ65 | φ70 | φ74 | φ100 |
| Tailstock taper | No | MT4 | MT5 | MT5# | MT5 |
| Tailstock travel | mm | 200 | 200 | 250 | 500 |
| Electric turret type | station | 8 | 8 | 8 | 8 |
| motor torque | X | N.M | 6 | 7.5 | 10 | 10 |
| Z | N.M | 6 | 7.5 | 10 | 10 |
| X travel | mm | 170 | 240 | 200 | 280 |
| Z travel | mm | 350 | 400 | 550 | 600 |
| Minimum setting unit | mm | 0.01 | 0.001 | 0.001 | 0.001 |
| Main motor | KW | 5.5 | 5.5 | 7.5 | 11 |
| weight | Kg | 2400 | 3000 | 4250 | 5000 |
| dimension | mm | 2200*1600*1850 | 2500*1700*1890 | 2950*1860*1850 | 3700*2000*2000 |
Company Profile
FAQ 1.Q: Which trade term I can choose? A: You can choose FOB,FCA 2.Q: How can I get quotation from you?
A: You can make the inquiry online on made-in-china, or send email to us. It is better if you can tell what is your detailed request information. We will reply to you within 24 hours on work days, and within 48 hours on holiday. 3.Q: how can I make the payment?
A: We can make the deal on made-in-china online platform, you can pay by T/T . You can also pay to my company business bank account. 5.Q:What is your delivery time ? A:The delivery depends on different machines with different configurations. Please contact us to confirm it is in stock or not. We want to know:
Please tell us your specific purchasing requirements, so that we can make specific quotations.
>>
