Industrial High Accuracy Extremely Precision Standard Customized Size Metal Slm 3D Printer

Product Description

Product Description
1. Big enclosed size: using integrated design, very easy to operate. 2. Simple operation: the software interface is friendly and easy to learn; integrated automatic centering function, the operator can easily place the crystal. 3. Strong adaptability: according to the movable requirements of the machine, the core components are equipped with a shock-proof system, which can effectively prevent damage to the core components of the machine due to accidental impact during equipment transportation and use. 4. Fast engraving speed: using galvanometer laser high-speed scanning working mode, the speed can reach up to 300,000 points/min, saving engraving time. 5. High stability and delicate engraving effect: using advanced air-cooled semiconductor end-pumped solid-state laser technology. 6. Adopt sealed integrated design, good beam quality, high stability, and delicate engraved dots. Can work stably for a long time. Product Parameters

Equipment Size	650mm*650mm*900mm
Print size	120mm*80mm
Production	80 crowns(4h)/6 frameworks(7h)
Machine Weight	200KGS
Powder Layer Thickness	0.03mm-0.1mm
Powder Delivery Method	Top-feed Powder Delivery
Powder Spread Method	One-way Powder Spread
Scanning Speed	7-12m/s
Control Software	Developed by GLOBAL LASER BOX (YM Build II )
Data Processing Software	VoxelDance
Laser Brand	BWT
Scanning System	PSI High Precision Scanning System
Beam Diameter	8-12μm
Laser Power	500W×1
Protective Gas	Nitrogen, Argon
Equipment Power	0.8KW
Operating Environment	Temperature 25±3°C, Humidity <75%
Supported Print File Format	STL
Automatic Setup and Monitoring Alarm	Supported

Company Profile
FAQ 1. What is the electrical configuration to install to power the machine, socket, power supply, electrical safety
• 120 M
Voltage 220V the socket can change local standards
• water cooling
Voltage 220V
• powder collector
Link the printer for power supply
2. Slicer software
• price
$1500/Year,$7000/Life time
• who does the maintenance
Software company
• Cost of maintenance and update
The fee includes maintenance and updates.
3. Information on chrome cobalt and titanium powders
• Heat treatment process for framework and coping/full unit and long bridge
Different powder have different heat treatment powder temperatures.
It is only related to the materials and has no relation to the printed products.
• Different granulometry offered
15-53μm
• Photo for marketing
• Packaging I must personalize
I do not recommend changing the manufacturer's name and logo
Because it involves a certificate.
4. Support disc chrome cobalt and titanium
• Thickness
20mm
• Fixing in the machine
Magnetic
• How many prints to recommend
Recommended printing times: over 200 times; grinding amount: remaining 8-9mm.
• How to surface after printing
Grinding bed, Hand Grinder
5. Photos and video of the technical parts of the machine
• Electrical compartment
• Laser compartment
• Filtration compartment
not available for now
6. Maintenance after photo and video printing
• Time for cleaning before reprinting
Cleaning time before reprinting: Clean the forming chamber for ten minutes.
• Annual maintenance
The permanent filter cartridge requires no maintenance and can print over 20,000 times.
• Cleaning the powder collector
Permanent filter element does not require cleaning.
• Water level of the water cooling
Add purified water above green.
7. Surveillance camera information
• Remote connection to PC and telephone
• Send a video so that I can check
8. Chrome printing times and quantity cobalt and titanium
• Framework
7-8
• Coping and full
80-90
9. how long is the training
• learn the slicer
• learn the machine software
• learn the machine start-up
• learn the post-processing
• learn the machine cleaning and collector
• learn the annual maintenance
About 3 days

---
