OEM Factory Price AC to DC Single Output SMPS Power Supplies High Quality Switching Power Supply Hlg-150-36 150W 36V SMPS

Product Description

Product Description OEM Factory Price Ac to Dc Single Output Smps Power Supplies High Quality Switching Power Supply HLG-150-36 150W 36V Smps
Features:
1. 95-264V AC Input
2. Protections: Short circuit / Overload / Over voltage / Over temperature
3. 100% full load burn-in test
4. Low cost, high reliability
5. 24 months warranty
Detailed Photos
Product Parameters

Model	HLG-150-12	HLG-150-24	HLG-150-36	HLG-150-48
DCoutput voltage,rated current	12V 12.5A	24V 6.3A	36V 4.2A	48V 3.2A
Wave andnoise	150mVp-p	151.2mVp-p	220mVp-p	220mVp-P
Line regulation	±0.5%	±0.5%	±0.5%	0.5%
Loadregulation	±2%	±0.5%	±0.5%	±0.5%
Efficiency	88%	90%	90.5%	91.5%
Voltage accuracy	±3%	±2%	±2%	±2%
Input voltage range	95~264VAC/135~373VDC 47~63Hz
Impact current	Cold start current 45A/230VAC
Overcurrent protection	95%~108%of therated output current starts overcurrent limit,recover automatically after abnormal conditions areremoved
Short circuit protection	Hiccup mode:recover automatically normal output after abnormal conditions are removed
Setup,rise,hold uptime	500ms,30ms,20ms/230VAC (atfullload)
Pressure resistance	I/P-O/P:1.5kV I/P-FG:1.5kV O/P-FG:0.5kV
Isolation resistance	I/P-O/P I/P-FG O/P-FG:100MOhms/500VDC/25ºC/70%RH
Working temperature	-20ºC~+60ºC
Dimension	170×69×43mm
Weight	0.75kg
Packing	20PCS

Certifications
Packaging & Shipping
Company Profile

FAQ Q1:Are you a factory or trading company?
A1:We are factory.
Q2:Why choose us
A2:We have been engaged in the switching power supply industry for 17 years,We have enough experience to meet your needs.
Q3:How can I get the samples?
A3:You can pay for the sample this time, and we will refund the sample fee for the next batch order.
Q4:How to order?
A7:Please contact us online to send you a proforma invoice or send us your purchase order by email.
Q5:How many years warranty of your switching power supply?
A8: Three years.

---
