High Precision Hydraulic Surfacel Grinder Machine M1320H X800

Product Description

Product Description
Detailed Photos
Product Parameters

Performence Features:
This machine is suitable for grinding cylindrical, conical shape internal, external and end face of various
middle and small size work piece.
With strong rigidity High precision High grinding efficiency.
It has strong cutting function Rigid.
Grinding head has the certain cutting edge.
Applicable to small batch production in the workshop and the use of the tool machine shop.
Technical parameter:

Specification & Model	Unit	M1320H x800
External grinding dia	mm	8-200
Internal grinding dia	mm	/
Center height	mm	135
Max travel of table	mm	950
Hydraulic traverse speeds	M/min	0.1-4
Max. Work piece weight	kg	50
Grinding length external/internal	mm	800
Swivel range of grinding wheel	.	-3-+7
Max.peripheral speed of grinding wheel	M/s	38
External wheel size	mm	Max dia400*50*200 / Min dia280*50*203
Internal wheel spindle rotating speed	R/min	/
Head and tailstock center taper		MT4
Machine motor power	kw	5.625
Overall dimension	mm	3000*1600*1500
Machine weight	kg	3000
Working accuracy
roundness	um	1.5
Uniformity of dia longitudinal section	um	5
Surface roughness	um	Ra<=0.32

Standard accessories:
Coolant lank
Grinding wheel dresser
Wheel flanges
Wheel balancing mandrel
Internal grinding
Three jaw chuck
Open type steady rest
Driving dog
Carbide tipped center
Support
Quill shaft for internal grinding
Chuck base
Optional accessories:
Center rest close type
Radius dresser
Wheel balancing stand
Company information
Packaging & Shipping
FAQ

1: What's your main products of your company?
A : We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining
Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
2:What kind of controlsdo you use on machines?
A :Siemens,GSK ,Fanuc etc. You can choose according to your requirements .
3. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
4 : How can I choose the most suitable machines ?
A : Please tell me the model or parameter you are interested in, we can provide you with the best price and quality.
You can also send us product pictures and we will choose the most suitable machine for you.
5 : Do we receive any updates while machine is in the manufacturing process?
A : Of course. The progress of the machine will be updated regularly and sent to you.

---
