High Accuracy Sg2540 3 Axis Vertical Automatic Machining Centre CNC Milling Machine

Product Description

High Accuracy SG2540 3 Axis Vertical Automatic Machining Centre CNC Milling Machine
Application:
It is suitable for aluminum mold, aluminum composite material, profile industries and rail transit industries.
Advantage:
At present, it is really widely used in the numerical control equipment of the rail transit industry such as aluminum molds and aluminum materials.
The original triangular balance rail structure of the beam, with the Z-axis balance auxiliary device, ensures the fast and stable processing of multiple curved surfaces.
The real three-axis linkage control is more suitable for the rapid processing and engraving of aluminum molds. It has powerful functions to ensure safe and efficient processing.
Automatic oil circuit lubrication system makes maintenance and maintenance more convenient.durability.
It has functions such as continuous carving at breakpoints, power failure recovery, and processing time prediction.
Using high-power servo drive system, with top accessories such as Taiwan mechanical spindle, so that the equipment has the characteristics of stable performance and long-lasting durability. Product Description

Product Parameters

Model	SG2540
Effective Process Stroke	X:2500mm(other size available) Y:4000mm(other size available) Z:1000mm(other size available)
Bed Structure	Overhead bridge gantry structure,heavy duty bed
Transmission Type	All Axes High precision Taiwan ball screw
Drive System	Servo drive system
Control System	Taiwanese Syntec controller
Spindle Power/Speed	Direct drive type mechanical spindle with servo motor,Max.Spindle speed 8000rpm/m
Max Cutter Clamp Diameter	32mm
Max.Move speed	45000mm/min
Max.Process speed	15000mm/min
Total Weight	According to the model
Command	G-code,F/S command
Working Table	Cast Iron table with T slot
Voltage	AC380V/50HZ

1.Automatic oil circuit lubrication system makes maintenance and maintenance more convenient.durability.d u r a b ilit yd u rdur a b ilit y
2.Possess functions such as continuous engraving at breakpoints,power outage recovery,and processing time prediction.
3.Extremely humanized design,com bined with ergonomic design of the height of the operation panel, modular design,meticulous and considerate,think what you think.
4.Using high-power servo drive system with topaccessories such as BT40 mechanical spindle and ltalian imported spindle,the equipment has the characteristics of stable performance and long-lasting durability
Company Profile
Shandong Honsiron Machinery Parts Co.,Ltd specialized in designing developing and producing various CNC machine and gantry machining centers. All the products have been approved by ISO9001:2000 and CE, we achieve ERP strategy and have independent right to export and import.
Manufacturing base in Qihe Economic Development Zone of Shandong Province,which with 13000 square meter modern plant, have over 200 workers and 20 professional technician and 15 after-sell service professional stuff.
More than 20 years machining experience has his own Professional R&D team,more than 20 engineers could design and produce 5 axis CNC machine,RV composite panels processing center,big mold CNC center and other high-end custom CNC equipment.
company advantage:
1.Professional R&D team: own kinds professional engineers, could design and produce 5 axis cnc machine, RV composite panels processing center, big mold cnc center and other high-end custom equipment.
2.Powerful machining capabilities:We own USA HASS Vertical Machining Center, USA HASS Horizontal Machining Center, Taiwan AWEA Gantry Five-Face Machining Center, kinds of boring machine and milling machine. More than 20 years machining experience to ensure the quality and precision of all mechanical spare parts;
3.Advanced testing equipment: We import UK RENISHAW brand laser interferometer / USA leader brand coordinate measuring machine / UK RENISHAW brand ballbar system, own Laser autocollimator / Optical edge finder Dial gauge, Dial indicator / square box / Marble square box and do insulation resistance text / ground resistance test / pressure test, to make sure all machine with the perfect performance before delivery.
4.24 hours online after-service and processional after-service team, to answer customer's question timely.
Shandong Honsiron Machinery Parts Co., Ltd has full-process machinery manufacturing capabilities, equipped with several American Haas CNC machining centers, Taiwan-made Asian CNC five-face milling, eight-axis welding robots, sandblasting machines, sheet metal production lines, plastic spraying production lines, and stress-relieving tempering furnaces. Advanced productionequipment, Renishaw laser interferometer, ballbar. Leighton coordinate, Easylaser laser calibrator and other precision testing equipment.
Certifications
FAQ
1. The first use of this machine, it is easy to operate? How about the training and installation?
---We could send the engineer to your factory for training and installation, and give you the technology support all lifetime.
2. If the machine has any problem after I ordered it, what could I do?
---Free parts send to you during the machine warranty period if the machine has any problem.
---If you need an engineer's support, we can fly to your company also.
3. Payment
T/T,L/C
4. You are a factory or trading company?
---We are a factory with the trading company, we not only can control the machine's quality by ourselves, but also we can provide better after-sales service by our engineers and technicians, this is our biggest advantage.
More info about the China 1325 3 axis wood furniture cnc router 3d making/milling/cutting machine price,kindly to send us offer ,we will reply you ASSP

---
