| Drivetrain | |
| Emission level | Tier 2 |
| Engine Manufacturer | Cummin |
| Displacement, ltr (in³) | 6.7(409) |
| Rated speed, rpm | 2000 |
| Engine output - net, kW (horsepower) | 125(169) |
| Number of support rollers - each side | 2 |
| Number of Track Rollers - Each Side | 8 |
| Track shoe width, mm (inches) | 600(24) |
| Transport length mono boom, mm (ft/in) | 9650 (31 feet 6 inches) |
| Transport Height - Maximum, mm (ft/in) | 3370 (11 ft 1 in) |
| Overall chassis width, mm (ft/in) | 3390 (11 ft 1 in) |
| Ground track length, mm (ft/in) | 3840 (12 ft 7 in) |
| Overall length of chassis, mm (ft/in) | 4640 (15 ft 3 in) |
| Tail swing radius, mm (ft/in) | 3140 (10 ft 4 in) |
| Ground clearance, mm (inches) | 460 (18) |
| Width on fixed rail, mm (ft/in) | 3390 (11 ft 1 in) |
| Track gauge, mm (ft/in) | 2590 (8 ft 6 in) |
| Digging Reach - Mono Boom, mm (ft/in) | 10910 (35 ft 10 in) |
| Height from Ground - Mono Boom, mm (ft/in) | 10750 (35 ft 3 in) |
| Digging Height - Mono Boom, mm (ft/in) | 10560 (34 ft 8 in) |
| Dump Height - Mono Boom, mm (ft/in) | 7580 (24 ft 10 in) |
| Digging Depth - 2.44m / 8'ft Flat Bottom, mm (ft/in) | 7440 (24 ft 5 in) |
| Digging Depth - Mono Boom, mm (ft/in) | 7610 (25 feet) |
| Standard arm, mm (ft/in) | 3610 (11 ft 10 in) |
| Fuel tank, ltr (gallons (US)) | 360(95) |
| Number of batteries | 2 |
| Voltage, V | twenty four |
| Ground bearing pressure, kPa (PSI) | 39.1 (5.66) |
| Swing speed, rpm | 12 |
| Swing torque, kNm (lbf / ft) | 77.5 (57150) |
| Travel speed - high, kph (mph) | 3.5-5.4 |
| Tractive force, kN (lbf) | 210(47220) |
| Arm tear, kN (lbf) | 114 (25628) |
| Bucket breakout, kN (lbf) | 150(33722) |
| Gradeability, % | 70 |
| End lift -7.5m Reach, kg (lbs) | 6070 (13050) |
| Sidelift-7.5m Reach, kg (lbs) | 3760 (8070) |
| Total flow, lt/min (gallons (US) / min) | 448 (118.4) |
| Bucket pressure, bar (PSI) | 343 (4975) |
| Boost pressure, bar (PSI) | 380 (5511) |
| Operating weight, kg (lbs) | 22000(48470) |
