Really Suggested Lens if target price is low, but don't want worse quality or low quality lens, this serial is the right one to you.
Whatsapp: 008618949838193
Wechat/Skype: soyocctv
Email: sales@soyocctv.com
Really Suggested Lens if target price is low, but don't want worse quality or low quality lens, this serial is the right one to you.
Whatsapp: 008618949838193
Wechat/Skype: soyocctv
Email: sales@soyocctv.com
25mm 2/3" 8Megapixel Machine Vision FA Camera Lenses 3.45μm F2.8 TV Distortion -0.061% AI 3D Positioning Industrial Recognition 4K C Mount Optics
High resolution : 8megapixel can used at 10Megapixel camera
Large format: 2/3" size covering 2/3", 1/1.8", 1/2" camera
Low distortion : -0.061% low distortion
Compact size : Very compact small size match all area applications.
Application : Positioning, Inspection for medical, life science, SMT, AOI.
Model
| SMV2528G-8M
|
Format
| 2/3” (Φ11mm)
|
Resolution
| 8.0 Megapixel
|
Focal Length
| 25mm
|
Aperture (Close)
| F2.8 Manual iris
|
Field of View (°)
| 2/3"
| 87.4*70*52mm | 25*20*15°
|
1/2”
| 63.4*51*38mm | 18*14.5*11°
|
1/3”
| 47.5*38*28.5mm | 13.6*11*8.2°
|
M.O.D
| 20mm
|
Distortion TV
| -0.061%
|
Filter Size
| M27*0.5mm
|
Magnification
| -0.12X @200mm WD
|
T.T.L
| 41.08mm
|
B.F.L
| 11.7mm
|
CRA
| 6.6°
|
Dimension
| Φ31*31.9mm
|
Mount
| C
|
Weight
| 65g
|
Marks
| -10℃～+40℃
|
>>
