Farm Machines Af88g 88HP Rice Wheat Corn Combine Harvester 80HP 100HP 150HP 180HP Harvesters

Product Description

Product Description
Combine harvester configured is to efficiently rake, using a raking auger. The ear-tip side part of divider-side grain stems harvested using a cutting blade device, and to prevent damage to the divider. A combine harvester according to the present invention is provided with a divider, a raking reel, a cutting-blade device, a raking auger, a platform, and a conveyor, wherein the combine harvester is characterized in that the raking auger is composed of a cylindrical drum, helical blades projecting from the outer circumferential surface of the drum, and being capable of lateral movement for orienting the grain stems to the conveyor, and a plurality of rod-shaped raking fingers capable of radially extending and retracting from the outer peripheral surface of the drum for guiding the grain stems to the conveyor. At least one of the fingers being provided in a position on the drum aligned within two pitches of receiving blades from the outermost effective receiving blade of the cutting-blade device end section to the inner side in plan view.
Product Parameters

Full Feeding Combine Hrvester AF88G
Product Model			AF88G
Overall dimensions	Length(mm)		5160
	Width(mm)		2750
	Height(mm)		2750
Weight(kg)			2970
Engine	Model		Dachai-DEUT ZCA498Z-09T2/01
	Structure type		Four-stroke,water-cooled, turbocharged diesel engine
	Rated power(kW)		65/88HP
	Rated speed(rpm)		2400
	Fuel type		Diesel(0#)
	Fuel tank(L)		95
Walking part	Track	Specification link	500*90*51
	Min ground clearance(mm)		325
	Gearbox type		HST
	Transmission type		(HST+3-gear) continuously variable-speed
	Theoretical traveling speed(km/h)		Low speed 0-3.96,Standard 0-5.14, Walk speed 0-7.37
Header system	Header width(mm)		2000
Threshing part	Threshing type		Vertical type axial-flow bar tooth type
	Threshing cylinder	Outer diameter(mm)	φ620*1790
		Rotate speed(r/min)	580
Grain unloading part	Grain tank capacity(L)		1400
	Unloading grain rotation range(Degree)		270
	Unloading grain height range(mm)		920-4200
Electrolyte and others	Battery	Voltage(V)	12
	Starting relay	Rated current(A)	50
		Vilotage(V)	12
	Hydulic oil tank volume		21
Hourly production(hm2/h)(Vertical dry field crops environment)			0.3-0.7

Detailed Photos
Company Production
SUPEREGN Industrial (Shanghai) Co., Ltd. is a leading Chinese construction machinery exporter, affiliated with SUPEREGN INDUSTRY LIMITED, located in the downtown of Shanghai City. Since our company was founded, we persistently introduce excellent Chinese construction machinery to international markets.
Our strengths are as follows:
(I) 16 years professional experience in international trading and rich knowledge in construction machinery & heavy equipment industry, which enable us to turn customer inquiries into final products and export them to numerous countries and regions without barriers;
(II) Proactive and high educated sales team with international vision, speaking fluent multiple languages, such as English, Spanish, Portuguese, Russian, Arabic and French etc.;
(III) Strong long term dealership from various top manufacturers, assuring that all our products are original brand new ones with competitive price;
(IV) Excellent logistics services (by sea, air, railway or road), ensuring timely delivery of consignments all over the world;
(V) Comprehensive after-sales service, including one-year warranty, spare parts supply, installment and maintenance, training and technical advice;
(VI) Expertly managed ERP system and coordinated quality control system to satisfy various project requirements.
SUPEREGN has passed the international quality management system of ISO9000, CE, SGS, UL and other products certification. Our export revenue increases constantly every year, and our products have already entered 168 countries across the continents of Africa, Middle East, South America, Oceania, Middle Asia, Southeast Asia, and East Europe. We sincerely hope to cooperate, develop together and build a good future with you. SUPEREGN, your genuine and professional
