Plastic PE PP PVC Film Lump Pipe Drum / Pet PC Bottle Barrel Pallet PP Woven Jumbo Bag ABS Shredder Crushing Washing Recycling Granulating Pelletizing Machine

Product Description

Product Description
We could supply complete set waste plastic recycling machines, such as single/ double shaft shredder, crusher, soft plastic PE PP film bags and hard plastic PE PP PET bottles, pipes, boxes, etc washing lines, as well as plastic granulating machines. Capacity from 200kg -2000kg/h.
If you need plastic recycling machines, please tell us what kind of plastic you want to recycle and the expected capacity per hour and other detailed requirements, we will make the best machine design for you.
Plastic granulating machine
Plastic Washing Line
Single Shaft Shredder:
The single shaft plastic shredder machine is mainly used in handling PE PP PVC ABS lumps, pipe, baled film, etc.
This single shaft plastic shredder machine is new designed especially for shredding various big solid materials, unmanageable materials, plastic container and barrel, plastic film, plastic pipe, fiber and paper which the normal crusher can not handle.
This plastic shredder machine has the advantages of stable running lower noise and big torque...
The materials are pushed into the shredding chamber by hydraulic. Independent drive system and solid structure make the running stably.
Shredder Features:
1)Precisely processed combined frame made of extra-thick plates; Lange-angle, hexagon prism of power slewing axis; Big hopper with big caliber for feeding big material
2)PLC control system with automatic overload protection and auto reverse switch
3)Unique hydraulic pushing system accelerates the shredding speed, for light material particularly
4)Each dynamic blades has four cutting edges which enable reutilization after being abraded, by rotating 90 degree
5)Each fixed blades has four cutting edges which enable reutilization after being abraded, by rotating 180 degree
6)Quiet operation at low speed
7)Screen perforation is adjustable according to customers' requirement
8)The shredders can be adjusted according to customer specific requirements for throughput volume, material to be processed, etc.

Model	SR-S600	SR-S800	SR-S1000	SR-S1200	SR-S1500
Shaft Length (mm)	600	800	1000	1200	1500
Shaft Diameter (mm)	220	400	400	400	400
Main Motor (KW)	18.5	37	45 / 55	55/75	75/90
Hydraulic Power (KW)	2.2	2.2	2.2	5.5	5.5
Rotary Blades (PC)	26	46	58	70	90
Fixed Blades (PC)	2	2	2	3	3
Capacity (kg/h)	200-300	400-600	700-1000	900-1200	1300-1600

Double Shaft Shredder
Plastic Crushing Washing Machines:
Plastic Granulating Machines:
Single & Double Rank Granulating Machines for rigid hard plastic
PE PP Film & Bag Granulating Machines
Plastic Recycling Machines shipped to oversea customers
Welcome to contact us if you are looking for plastic crushing, washing and granulating machines.

---
