| US$3,000.00 | 1 Piece (MOQ) |
| Pulsed CO2 Laser | 10W | 30W | |
Input power | Input voltage: AC220V Frequency: 50 Hz Input power: ≥1000W | ||
| Wavelength (nm) | 930-1064 | 930-1064 | |
| Normal average output power (W) | ≥10 | ≥30 | |
| Single pulse energy(MJ)@20khz: | 1 | 1@30kHz | |
| Beam quality | <1.8 | <1.8 | |
| Beam Diameter(mm) | 6~8 | 6~8 | |
| Pulse duration(ns)@20kHz | <120 | <120@30kHz | |
| Pulse repetition rate(kHz) | 20~60 | 30~60 | |
| Output power tunability(%) | 10~100 | 10~100 | |
| Output fiber cable length(m) | 2.0 | 2.0 | |
| Power consumption(20ºC)(W) | 200 | 300 | |
| Modulation frequency | 20kHz ~ 80kHz | ||
| Dimension WDH (mm) | 250*100*160 | ||
| Marking range | 160*160mm 110 * 110mm 70 * 70mm (optional) | ||
| Maximum scanning speed | 0-150m / s | ||
| Scan accuracy error | <2 mrad | ||
| repetition error | <5 μrad | ||
| Minimum line width | 0.02mm | ||
| Line depth | 0.04 ~ 0.2 mm (depending on material) | ||
Field Focal Length (optional) | F = 100mm Effective Focus Scanning Range: 70 * 70 mm F = 160mm Effective focus scanning range: 110mmX110mm | ||
Working environment | Should work in dust-free, smoke-free, non-corrosive gas work environment Temperature: 0 ~ 42 ºC Humidity: 45 ~ 85% | ||
| Cooling way | Forced air cooling ,( 3 fans in the laser, each fan is 75.2 CFM ) | ||
| Safety | over-current protection; over-temperature protection; over-voltage protection | ||
| Approximate weight | 70~90kg with the wooden case | ||
Controller | Window IPC i32.5G, 500G, 2G, 19-inch LCD(Static marking) Touch screen (fly marking) | ||
| Language | Chinese English(touch screen) | ||
