Shantui 13ton Capacity 0.55cube Hydraulic Crawler Excavator

Product Description

SHANTUI 13ton Capacity 0.55cube Hydraulic Crawler Excavator

Our company will offer you the high quality products with a low price, quick delivery,and professional after-sale service.
Qingdao Chary Machinery CO., LTD

SHANTUI 13ton Capacity 0.55cube Hydraulic Crawler Excavator

The engine systme
The engine cooling system	cool -watering
The type	QSF3.8T
cylinders *diameter *trip(mm)	4*102*115
The displacement(L)	3.76
Rated power(kw/rpm)	86/2200
The bucket
The capacity of bucket(m³)	0.55
The width of bucket(mm)	990
Digging force
Arm digging force(kn)	70
Bucket digging force(kn)	97
The walking system
The Walking motor	The axial variable
The number of the segments	2*44
The walking speed(km/h)	3.25/5.2
The traction(KN)	135
The climbility ability	70%(35°)
The track roller number	2*7
Drag chain number	2*1
The hydraulic system
The hydraulic types	Variable double column
The rated working flow	2*130
Walking circuit pressure(Mpa)	35
Rotary loop pressure(Mpa)	27
Pressure control loop(Mpa)	3.9
Rotary system
The rotary speed(r/min)	11.3
The brake type	Pressure release,Mechanical brake
The oil capacity
Fuel tank capacity(L)	220
The cooling system (L)	20
Amount of engine oil(L)	12
The hydraulic oil tank(L)	177/205
The weight and the ground pressure
The weight(kg)	13500
the ground pressure(Kpa)	41.5

SHANTUI 13ton Capacity 0.55cube Hydraulic Crawler Excavator

QSF3.8 T engines, electronically controlled high pressure common rail injection system, energy conservation, environmental protection, low noise, strong power, China emission standards; Fuel system adopts three-level integration diesel oil filter, air intake system using radial seal air filter, the standard air prefilter, effectively prolong the service life of the engine; Tied for radiator, aluminum radiator area is large, the cooling performance is good

World famous brands imported hydraulic components, constant power, the electric proportional control of the double pump double negative flow hydraulic system, the system is stable and reliable;

Independent intellectual property rights system of intelligent control system, embedded GPS module, GPRS module, realizing remote monitoring and two-way transfer data, real-time capture the machine running state; The throttle control quickly and accurate; Using nonlinear multidimensional optimization of power control, improve work efficiency, reduce the fuel consumption. Preset P (overloading), E (economic), A (automatic control) and B (hammer) operation mode, the user can choose job freely according to the actual working
condition mode. Friendly human-computer interaction interface, easy to operate
