| US$17,450.00-19,010.00 | 1 Set (MOQ) |
| Machine parameters | |
| Model | SD25U |
| Operating Weight | 2.5 ton |
| Bucket Capacity | 0.1m³ |
| Rated Power | 14.7 kw , 15.2kw |
| Max.Hydraulic System Pressure | 18mpa |
| Ground Pressure | 35kpa |
| Max. Grade ability | 30° |
| Max Walking Speed | 2.8-4.1km/h |
| Max Digging Force | 16kn |
| Platform Rotary Speed | 14 r/min |
| Boom swing function | yes |
| Dimensions | |
| Overall Length | 3950mm |
| Overall Width | 1300mm |
| Overall Height | 2300mm |
| Arm Length | 950mm |
| Boom Length | 1950mm |
| Track Length | 1870mm |
| Track Width | 250mm |
| Platform Width | 1330mm |
| Platform Ground Clearance | 480mm |
| Bucket Width | 450mm |
| Working range | |
| Max. Digging Height | 4300mm |
| Max Digging Depth | 2550mm |
| Max. Digging Radius | 4150mm |
| Max Dumping Height | 2530mm |
| Radius of Gyration | 1800mm |
| Max. Sinking Depth of Bulldozer | 300mm |
| Max. Lifting Depth of Bulldozer | 330mm |
| Machine configure | |
| Engine Model | Perkins , Yanmar |
| Main valve | Taifeng |
| Main Pump | Taifeng (Plunger pump) |
| Rotation Motor | Eaton |
| Walking Motor | Eaton |
| FAQ 1.How long is the mini excavator warranty time? A: One year. 2.which certification of mini excavator do you have? A: CE, ISO900 1, SGS,etc. expect these for different countries, other certificates required by the customer are agreed upon. 3.Is it convenient to see visit your factory and how to go there? A: Welcome everyone to come to visit our factory, we are in Dezhou city, near Jinan airport. Also, a high-speed train arrives in our city. Make sure your trip date we will arrange it for you. 4.What are our advantages compared with Manufacturers/Factories? A: Competitive Price-we work as the leading dealers of various leading China construction machinery, and are treated with the best dealership prices every year. From numerous comparisons and feedbacks from clients, our price is more competitive than Manufacturers/Factories. Quick Response-Our team is consisted of a group of diligent and enterprising people, working 24/7 to respond to client inquires and questions all the time. Most problems can be solved within 12 hours. 5.How long will our price be valid? A: We are a tender and friendly supplier, never greedy on windfall profit. Basically, our price remains stable throughout the year. We only adjust our price based on two situations: (1) The rate of USD: RMB varies significantly according to the international currency exchange rates. (2) Manufacturers/Factories adjusted the machine price, because of the increasing labor cost, and raw material cost. |
