Shutter Cone Fan Axial Flow Air Cooling Fans Ventilation Exhaust Fans for Poultry Chicken Layer Broiler House Poultry Farming Livestock Machinery

Product Description

DJF(C) Series Shutter Cone Fan


Product Application:
DJF(C) Series shutters cone fan is widely used in Agriculture and industry ventilation and cooling. It is mainly used for animal
husbandry, poultry house, livestock breeding, greenhouse, factory workshop, textile etc. Main Features:
1) Hot-dip galvanized plate adopt 275g/sqm galvanized layer, not rust.
2) 95% of the parts are produced by ourselves, reducing the cost of processing ,sharing profits with customers, ensuring quality ,
utmost cost-effectiveglobally
3) Complete CNC production line, the accuracy of assembling holes is 100%, easy to assemble, quality assured.
4) Wall-Mounting fan , easy installation and maintenance
5) Belt Drive, Big airflow Technical Parameter:

Model	Drive	Blades Diameter	Blades Rotational Speed	Motor Rotational Speed	Air Flow (m³/h)	Noise Decibels (db)	Input Power (W)	Voltage (V)	Frequency (HZ)	Outline Size (H*W*T) (mm)
DJF(c)-750	Motor Direct	610mm	960rpm	960rpm	11000	≤70	370	220 / 380/ Customized	50 / 60	750*750*1080mm
DJF(c)-900	Belt	750mm	630rpm	1400rpm	22000	≤65	370			900*900*1100mm
DJF(c)-1000	Belt	910mm	610mm	1400rpm	25000	≤65	550			1000*1000*1180mm
DJF(c)-1100	Belt	1000mm	600rpm	1400rpm	32500	≤64	750			1100*1100*1280mm
DJF(c)-1220	Belt	1100mm	460rpm	1400rpm	38000	≤64	750			1220*1220*1280mm
DJF(c)-1380	Belt	1250mm	439rpm	1400rpm	44000	≤64	1100			1380*1380*1480mm

Product Description:

	Cone and Shutter 1.Reasonable Cone design for bigger exhaust power, Large airflow and steady air output 2.Aluminum alloy shutters for light weight and attractiveness.
Frame Hot Galvanized sheet with zinc thickness of 275g/sqm, avoiding rust effectively. Rubber Sealing Rubber sealing device is equipped for the double door close to avoid the air backflow. Greatly improved the running efficiency compared with the same power fan
	Bearing Imported double-row bearing with special waterproof design. Advantage: High strength, low noise, free maintenance and long service life.
Blade Support Base 1.Material: Aluminum Magnesium Alloy. 2. Type: Plug-in connection Advantage: Compare with the traditional welding connection , Our new type Aluminum magnesium alloy base has greatly reduced the friction coefficient, fixed more firmly, avoided
	Belt Pulley 1. Material: High strength aluminum-magnesium alloy by die-casting. 2. Blast-sanding treatment, eliminate internal stress to improve its own rigidity and stability Advantage: Light weight, Low vibration ,attractive appearance.
Belt Brand: Mitsuboshi belt (Japanese) Type: B type, B88 Advantage: B type belt is 3 times longer service life than A type belt, maintenance free.
	Motor 1. Brand: Chinese famous motor, Siemens motor, ABB motor and WEG motor 2. Motor Protection Grade: IP55 3. Isulation Class: F grade Advantage: Motor voltage and frequency can be customized. Chinese famous motor OEM by special design for fan, the first put in the phase lack protection device which would power off when shortage of electricity.

About our Company
Shandong Yuyun Sanhe Machinery Co.,Ltd is the biggest and the most professional manufacturer of ventilation equipment in
China,equipped with the most advanced CNC production lines and laser cutting machines, top quality level in the industry.

---
