| US$15,000.00-18,000.00 | 1 set (MOQ) |
| Item | Specification | Unit | BL-Y25 |
| Worktable | Table size | mm | 700×260 |
| T slot(NO./width/gap) | mm | 3/14/63 | |
| X/Y/Z axes | X/Y/Z axes travel | mm | 400/250/280 |
| X/Y/Z axes ball screw(dia./pitch) | mm | 32/6 | |
| Cutting feeding speed | m/min | 6~10 | |
| Rapid moving speed | m/min | 15 | |
| Positioning precision | mm | ±0.01 | |
| Repeatable positioning precision | mm | ±0.008 | |
| Spindle | Max. distance from spindle nose to worktable surface | mm | 380 |
| Distance from spindle center to column surface | mm | 250 | |
| Spindle type | / | BT40 | |
| Spindle motor | kw | 2.2(inverter) | |
| Spindle speed | rpm | 6000 | |
| Tool magazine | Tool magazine type | / | N/A |
| Others | Overall size(Half closed cover) | mm | 1510×1200×2010 |
| Overall size(Full closed cover) | 1760×1840×2010 | ||
| N.W.(Half/Full closed cover) | kg | 1300/1500 |
| Item | Brand |
| Ball screw bearing | CHINA top-HRB P4 class/Z axes NSK |
| Ball screw | CHINA top |
| Dishing spring | GERMANY |
| Spindle unit | TAIWAN |
| Inveter | TAIWAN TECO/JAPAN YASKAWA |
| Booster cylinder | TAIWAN |
| Pneumatic parts | TAIWAN-AIRTAC |
| Electricity parts | FRANCE-SCHNEIDER |
| Lubrication pump | Joint-venture |
