| 200W High-Definition Camera | Equipped with a 200-megapixel camera offering crisp visuals, it boasts 30x optical zoom and 10x digital zoom for high resolution support up to 1080P, ensuring clear and detailed images. |
| Low Light Performance | Capable of capturing color images at 0.05lux@F1.6, making it ideal for low-light environments. |
| Automatic Color to Black & Night Vision | Features automatic color to black conversion for seamless day-to-night monitoring, complemented by infrared night vision for enhanced visibility in darkness. |
| Backlight Compensation | Enhances image quality in challenging lighting conditions with backlight compensation. |
| Comprehensive Status Display | A built-in small screen displays real-time battery level, GPS status, 3G/4G status, recording status, remaining storage time, platform connection status, and WiFi status. |
| Digital Wide Dynamic Range (D-WDR) | Enables clear visibility in high-contrast scenes, optimizing image quality. |
| 3D-DNR (3D Digital Noise Reduction) | Reduces noise in videos, enhancing clarity and smoothness. |
| Dual TF Card Storage | Supports simultaneous recording on two TF cards for extended storage capacity and backup. |
| GB28181 Protocol Support | Compliant with the national standard GB28181, ensuring seamless integration with various surveillance systems. |
| 4G Module Flexibility | Comes standard with a single 4G module, but can be expanded with up to two additional 4G modules for enhanced connectivity. |
| Removable Batter | Equipped with a replaceable battery that supports up to 9 hours of continuous operation, ensuring reliable power supply. |
| Audio Capabilities | Includes a MIC and speaker, with optional support for LINE IN/LINE OUT for advanced audio recording and playback. |
| Customizable Voice Alarm | Enables users to set custom voice alerts for specific events or conditions. |
| High-Suction Magnet Base | A bottom-mounted high-suction magnet facilitates easy and secure installation in various locations. |
| Video Streaming & Playback | Enables real-time video transmission and playback of recorded footage, allowing users to monitor and review events as they happen or at a later time. |
| Pan-Tilt-Zoom (PTZ) Control | Provides remote control over the camera's movement, allowing users to adjust its pan, tilt, and zoom functions to capture footage from different angles and distances. |
| Satellite Positioning (GPS) | Integrates GPS technology for precise location tracking, ensuring the device's whereabouts are known at all times. |
| Two-Way Intercom | Supports two-way audio communication, enabling users to engage in live conversations through the device's microphone and speaker system. |
| Infrared & Starlight Night Vision | Combines infrared and starlight technology for unparalleled night vision capabilities, ensuring clear and detailed footage even in the darkest conditions. |
| Remote Control | Fully controllable from a remote location via smartphone app, web browser, or dedicated control panel, providing users with unparalleled flexibility and convenience. |
| Advanced Surveillance Capabilities | With these features, the device becomes a comprehensive surveillance solution, suitable for a wide range of applications including security monitoring, wildlife observation, remote site management, and more. |
| Name | Parameters |
| Sensor type | 1/2.8" Progressive Scan CMOS |
| signalling system | PAL/NTSC |
| Minimum illuminance | colour:0.05Lux @(F1.6,AGC ON) black and white:0.01Lux @(F1.6,AGC ON) |
| Day night conversion mode | ICR infrared filter |
| Signal to noise ratio | >56dB |
| focal length | 4.5-135mm |
| Electronic Shutter | 1/1 s~ 1/30,000 s |
| Number doubling | 10 times |
| resolving power | Main stream:50HZ:25fps(1920x1080) 60HZ:30fps(1920x1080) Sub stream:50HZ:25fps(1280x720) 60HZ:30fps(1280x720) |
| white balance | Automatic 1/Automatic 2 |
| 3D noise reduction | support |
| Optical zoom | 30 times |
| Horizontal rotation angle | 360° |
| Vertical rotation angle | -20°~90° |
| Pre-set position | 256, 8 cruise scans |
| storage | Supports dual TF cards, with a maximum support of 256GB per card |
| network | FDD-LTE:B1,B3,B5,B8 TDD-LTE:B38,B39,B40,B41 WCDMA:B1,B8 TD-SCDMA:B34,B39 CDMA:BC0 GSM900,1800MHz |
| Positioning | beidou+GPS |
| Power supply | DC 12V |
| WiFi | 2.4GHz /5GHz, 802.11b/g/n/ac,WIFi AP |
| Audio input | Dual MIC |
| Audio output | speaker |
| Infrared fill light distance | 100m to see the outline of the human body clearly |
| Video encoding format | H.264,H.265,smart264 |
| Working temperature | -10ºC~55ºC |
| humidity | < 95%(No condensation) |
| Waterproof Degree | IP66 |
