| US$552.00-732.00 | 1 Box (MOQ) |
| NO.: | Product name | technical parameter | |||
| 1 | Pixel Pitch(mm) | 2.6mm | |||
| 2 | Pixel configuration | 1R1G1B/SMDlamp | |||
| 3 | Pixel density | 147456dots/sqm | |||
| 4 | Brightness | ≥1200-5000cd/sqm | |||
| 5 | Module size(W*H) | 250mmx250mm | |||
| 6 | Module Resolution (W*H) | 96dots x 96dots | |||
| 7 | Module weight | 700g | |||
| 8 | Cabinet size (W*H) | (500mm×500mm) or (500mm ×1000mm ) | |||
| 9 | Drive IC | MBI5124/MBI5153/ICN2053 | |||
| 10 | Drive mode | 1/24scan | |||
| 11 | Viewing Angle(V/H) | 160 ºC | |||
| 12 | Grey Scale | 65536 degree | |||
| 13 | Lifetime | >100,000 Hours (80%) | |||
| 14 | MTBF | >50,000 Hours | |||
| 15 | Operating Voltage | AC110V/220V±10% | |||
| 16 | Screen Power Consumption | Max: 600w/sqm; Average:300w/sqm | |||
| 17 | Input Power Frequency | 50/60Hz | |||
| 18 | Operating temperature | -30--60ºC | |||
| 19 | Humidity | 10%-95% | |||
| 20 | Refresh Rate | ≥1920HZ - ≥7680HZ | |||
| 21 | Control Method | Synchronized with the computer monitor | |||
| 22 | Color Temperature | 6500K-9500K | |||
| 23 | LED control system | LINSN, Nova-star, and Colorlight is selectable | |||
| 24 | Control Distance | 100 m (no repeating); Optical fibre transmission: 500m- 15km | |||
| 25 | Accepting signal with video processor | PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI | |||
| 26 | Systems Operating Platform | Windows Series | |||
