| Model | 3000W | 5000W | 3000W | 5000W | ||||
| Battery rated voltage(vdc) | 25.6 | 25.9 | 44.4 | 51.2 | 44.4VDC | |||
Inverter | Rated power(w) | 3000W | 5000W | 3000W | 5000W | |||
| Input voltage range(vac) | 85-138VAC/140-275VAC | 85-138VAC/140-275VAC | ||||||
| Input frequency(Hz) | 45-65 | |||||||
| Output voltage(vac) | 110/220 | |||||||
| Output frequency(Hz) | 50/60 | |||||||
| Output wave | Pure Sine Wave | |||||||
| Speficifation of built-in battery | 150AH 172AH | 106AH 144AH | 106AH 150AH | 86AH | 80AH | 100AH | ||
| MPPT Solar Input | MPPT Voltage Range | 30V~150VDC | 60V~150VDC | 30V~150V | 60V~150V | |||
| PV Power | 800W | 1350W | 3200W | 1600W | 3200W | |||
| Rated charge current | 30A (Max) | 60A (Max.) | 30A(Max) | 30A/60A(Max) | ||||
| MPPT efficiency | ≥99% | |||||||
| Floating charge voltage | 50.4VDC | |||||||
| OutPut | Voltage for high voltage protection | 34VDC | 34VDC | 58VDC | 66/60VDC | 58 VDC | ||
| High voltage recovery voltage | 31VDC | 31VDC | 52VDC | 60/56VDC | 52 VDC | |||
| Low voltage recovery voltage | 25VDC | 26VDC | 44VDC | 51/48VDC | 44 VDC | |||
| Low voltage protecton voltage | 22VDC | 22VDC | 36VDC | 45/43VDC | 36 VDC | |||
| 5VDC USB output | Max. 2A *2 | |||||||
| 12VDC output ports | Max. 2A *2 | |||||||
| Heat dissipation/Cooling | Temperature control by intelligent exhaust fan | |||||||
| Operating ambient temperature | -20 - +50ºC | |||||||
| Storage ambient temperature | -25 - +55ºC | |||||||
| Operating/Storage ambient | 0-90% No condensation | |||||||
| External size:W*D*H(mm) | 620*420*580 | 515*397*530 | ||||||
| Package size:W*D*H(mm) | 720*520*760 | 605*490*711 | ||||||
