Laboratory Vertical Ball Milling Machine Grinder Machine for Sale

Product Description

Laboratory Vertical Ball Milling Machine Grinder Machine For Sale
Product Description ACEY-MPM-2L can be performed dry, in suspension or in inert gas. In addition to comminution, you can also use the mills for mixing and homogenizing of emulsions and pastes or for mechanical alloying and activation in material research. The instrument has small volume, complete function, high efficiency and low noise. It is the ideal facility to acquire research samples for research institutes, universities as well as enterprise laboratories (can acquire four samples in one experiment). If mated with vacuum ball milling tanks, it can grind samples in vacuum status. The products are extensively applied to in the fields of Geology, Mining, Metallurgy, Electronics, Construction Material, Ceramics, Chemical Engineering, Light Industry , Environmental Protection etc.
Features 1.Elegant design, easy to operate
2.Ideal for wet or dry grinding application
3.Automatic and programmable control with LED display
4.Multiple grinding modes to choose
5.High Uniformity and excellent repeatability
6.Fast rotational speed, high efficiency and fine granularity
7.Four samples with different sizes and materials in one experiment
8.Programmable interval and pause times
9.Stepless speed regulation, reversing function
10.Large range of materials available for grinding tools
11.Gear-drive offers an effective solution to problems caused by belt driving
12.Low center of gravity, good rigidity, compact structure, low noise, safe and reliable operation, no pollution and small wear
13.Cooling of the grinding chamber with a built-in fan for long grinding times
Product Parameters

Product Name	Vertical Planetary Ball Mill
Model No	ACEY-MPM-2L
Working Principle	Impact and friction force
Compatible Grinding Jars	2L:(250ml~500ml) * 4 / 4L:(250ml~1000ml) * 4
Max Feeding Capacity	2/3 capacity of the grinding jar
Operation Mode	2 or 4 grinding jars working simultaneously
Max Feeding Granularity	15mm
Mini Discharging Granularity	Down to 0.1m
Sample Type	Hard, medium-hard, soft, fibrous, brittle, moist
Rotational Speed of Grinding Jar	800rpm
Rotational Speed Ratio	1: 2
Drive Mode	Gear drive and belt drive
Speed Control	Stepless speed regulation
Electrical Details	110V /220VAC, 50/60Hz, single phase,0.75KW
Max Continuous Grinding Time	72hours (full-load)
Weight	85KG
Dimension (L*W*H)	730mm*470mm*550mm
Effective Diameter of Planetary Disk	~340mm

Q1:How to order?A: Please send us your purchase order by email or call us sales, or we can make the proforma invoice under your request.We need to know the following information for your order before sending your Pl. Payment methods? T/T, L/C, D/P and so on.
1)Product information-quantity, specification(size, material, technological if needed and packing requirements etc.)
2)Shipping information-company name, street address, phone number,destination sea port. Q2: How to control quality?A,All the raw materials by IQC(Incoming Quality Control) before launch whole process into the process after the screening,
B, Process each ink in the process of IPQC(Input Process Quality Control)patrol inspection.
C, After finished by QC full inspection before packing into the next process packing.
D, OQC before shipment for each slipper to do full inspection.Q3:How do I install and operate the machine myself?A: Our system development is based on the integrated development view, when you get the machine, just connect it to the power supply and the machine is ready to work, as the English software is already installed on the machine, all you need to do is to learn how to use the software, a complete English user manual will be sent to you with the machine.Q4: How do I get technical support after purchase?A: Our factory provides online technical support in English, you can get to know us easily online through Skype, Wechat, WhatsApp or E-mail. If you need any remote assistant support, we will support you through Team viewer software.Q5:What's the warranty for the items?A: We are very confident in our products and we package them very well so you will usually receive your order in perfect condition. The warranty on the equipment is one year (12 months) and if any part of the equipment is damaged within one year due to non-human factors, we will provide a replacement part free of charge.Q6:Can I customize products?A: Yes, OEM&ODM is available! we can provide not only standard machines but also customized machines according to your requirements. Don't hesitate to tell us your requirement, we will try our best to meet your needs.

---
