Fast Speed Auto Thermal Forming Parts 3D Laser Cutting Machine Autobot Series 3D Laser Cutting Machine for Sale

Product Description

AUTOBOT3015 Auto Thermal Forming Parts 3D Laser Cutting Machine
AUTOBOT3015 auto thermal forming parts 3D laser cutting machine is a kind of 3D 5 axis laser manufacture equipment developed specially for auto thermal forming section, mainly used for hole boring & edge cutting for high-strength steel with higher precision, higher speed and better dynamic performance. Assembled with high performance rotation work table, can meet the efficiency in auto section.
Advantages:
1.Stability: designed in elevated gantry structure, comparing with cantilever structure,more stable.
2.High acceleration:higher positioning speedguarantee cutting efficiency and precision in long-term.
3.High efficiency: maxsimultaneous speed is 166m/min, max simultaneous acceleration is 1.7G, minstation shift for rotation work table is 3s, and max cutting speed is 30m/min.
4.Multi-station: realizerapid machining for different parts, and automatically loading and unloading.
5.Security: machineprotection device meet with international standard CE/CDRH.
6.Cost efficiency: performance as good as foreign brand, shorter delivery period, moreflexible budget, lower maintanance cost.
Features:
1.Axis rotate unlimitedly
2.Max positioning speed:360°/s
3.Quick boring
4.Auto focusing
5.Small angle parts cutting
6.Crash protection
Technical Parameters

AUTOBOT	Parameter
Working Range
Working Range (Length×Width)	3000mm×1500mm
X-Axis	3000mm
Y-Axis	1500mm
Z-Axis	680mm
A-Axis	±135°
C-Axis	±n×360°
Accuracy
X/Y/Z Axis Position Accuracy	0.08mm
X/Y/Z Axis Repeat Accuracy	0.03mm
A/C Axis Position Deviation	0.015°
A/C Axis Repeat Accuracy	0.005°
Speed
X/Y/Z Axis Max Speed	100m/min
A/C Axis Max Speed	540°/s
X/Y/Z Axis Simultaneous Max Acceleration	10m/s²
A/C Axis Simultaneous Max Acceleration	60rad/s²
Dynamic Axis Range	±12.5mm
Work Table
Rotation Work Table	Rotation diameter:4000mm
	Side max. load:400kg
	Min shifting time:≤2.3s
Power
Phase No.	3
Rated Voltage	380V
Frequency	50Hz
Protection Level	IP54
Weight & Size
Net Weight	≤16000kg
Space Size(Length×Width×Height)	8500×7600×4200mm

Industry case
Automotive Thermoforming Industry Industry Background
The application of thermoforming technology can reduce the body mass, improve fuel economy, and achieve energy saving and emission reduction. High-strength steel, with its high hardness, high toughness and high wear resistance, is widely used in the field of automotive thermoforming.China's first set of 3D Five-Axis laser cutting machine for high-strength steel thermoforming parts - AUTOBOT solves the problem of difficult punching of high-strength steel, replacing a large number of punching and trimming dies.

The machine can cut automotive thermoformed parts 24 hours a day, and can produce up to 1,000 pieces of B-pillars for this model in one day. It is equipped with high-speed rotary worktable and a new generation of independently developed high-performance cutting head, it can meet the production rhythm requirements of the automobile hot forming industry to the greatest extent.

Industry Achievements

1.In April 2018, the equipment was awarded the first prize of Hubei Provincial Science and Technology Progress.
2.In October 2022, the 3D Five-Axis laser cutting intelligent equipment of Huagong Technology's intelligent manufacturing business ushered in the delivery of breaking 200 units in the thermoforming industry.
3.With the third generation of self-developed lightweight 3D Five-Axis cutting head, the market share steadily ranks the first in China.

Sample
Company Introduction:
Wuhan Huagong Laser Engineering Co.,Ltd is one of the largest laser equipment manufacturers in China. HGLASER is the main subsidiary company of Huagongtech Co., Ltd. (Stock code: 000988)
HGLASER is a national key high-tech enterprise, possessing technology centers and provincial key laboratories. Relying on the National Engineering Research Center for Laser Processing, National Key Laboratory for Laser Technology and Exhibition Center for Laser Technology Processing, HGLASER undertakes national key projects and scientific research projects.
Wuhan Huagong Laser Engineering Co.,Ltd possesses HGLASER and FARLEY?LASERLAB two famous brands. HGLASER has always been committed to providing broad and comprehensive laser manufacturing solutions in industrial manufacturing field, researching, manufacturing and selling various laser processing and plasma machining equipments, providing tube laser cutting processing and oil pipeline trade services. The main products of HGLASER cover the full power series of laser cutting systems, laser welding systems, laser marking series, laser texturing equipments, laser heat treatment systems, laser drilling machines, laser devices, all kinds of support devices, laser processing and plasma machining equipments, which are used widely in metallurgy, non-ferrous metals, automobiles, parts, aviation, precision instruments, machine manufacturing, hardware, integrated circuits, semiconductor manufacturing, solar, education, communication and measurement, packaging, leathers, plastics, rubbers, jewelries, crafts, medical equipments, etc.
