| CAPACITY | Swing over bed | mm | 440 |
| Max. turning length | mm | 450 | |
| Max. turning diameter ( shaft / disc ) | mm | 260/300 | |
| Guideway type | Linear guideway | ||
| SPINDLE | Chuck size | Inch | 8 |
| Spindle nose | ISOA2-6 | ||
| Spindle bore | mm | 62 | |
| Spindle speed | rpm | 4500 | |
| Spindle motor power | Kw | 11/15 | |
| Spindle torque | Nm | 93/127 | |
| Max bar diameter | mm | 51 | |
| TRAVEL | X-axis travel | mm | 160 |
| Z-axis travel | mm | 500 | |
| X-axis rapid traverse | m/min | 20 | |
| Z-axis rapid traverse | m/min | 24 | |
| TOOL POST | Turret type and tool number | Hydraulic 8-station turret | |
| Tool shank size | mm | 25x25 | |
| Indexing time(adjacent/farthest) | s | 0.45/1.2 | |
| TAILSTOCK | Diameter of tailstock quill | mm | 80 |
| Tailstock quill travel | mm | 130 |
