Professional Engine Lathe Machine Horizontal Manual Lathe Metal Torno Cn6250b/2000

Product Description

√ Experience the pinnacle of durability and precision in body machining with our superior machine guide way. This gem achieves an extraordinary hardness of over HRC52° thanks to the application of a state-of-the-art high-precision CNC guide way grinding machine. The result? Exceptional longevity paired with outstanding accuracy, offering you the finest in machining performance.
√ The lathe head box, feed box, and sliding box are masterfully crafted using cutting-edge CNC machine center machining. This meticulous process ensures that each box meets the peak of machining precision, aligning each component with the highest standards of excellence and quality.
√ Enjoy the luxury of ultra-low gear noise with our transmission gear, designed through precise CNC gear grinding machining. Coupled with stringent noise testing, this ensures whisper-quiet, smooth operation, elevating your overall experience.
1. Quenched Guideway
The quenched guide rail is a paragon of hardness and wear resistance, promising unmatched durability and superior performance that stands the test of time.
2. Tool Post
Enhance your lathe's versatility with a standard 4-position tool post, while the optional quick-change tool post offers even greater flexibility for your machining needs.
3. Three-Jaw Chuck
Equipped with a standard 3-jaw manual chuck, you have the option to expand your capabilities with a versatile 4-jaw chuck, enabling a broader scope of machining tasks.
4. Tailstock
Engineered with a standard manual tailstock, it is tailored for seamless handling of shaft bar workpieces, enhancing efficiency and effectiveness in operations.
5. Working Light
Includes a working light to significantly boost operator convenience and simplify operations, ensuring ease and clarity.
Professional Engine Lathe Machine Horizontal Manual Lathe Metal Torno CN6250B/2000

Model			CN6250
Max swing over bed		mm	500
Center height		mm	250
Max work piece length		mm	1000, 1500, 2000, 3000
Bed rail width		mm	390
Max turning diameter of work piece on tool holder		mm	300
Max turning diameter of workpiece in saddle groove		mm	710
Valid length of gap		mm	240
Through hole diameter		mm	82
Bore hole		mm	90/1:2
Spindle rotation speed		rpm	9-1600
Max transverse travel of tool rest		mm	360
Max travel of small tool rest		mm	145
Distance between spindle center line and tool support surface		mm	about 28
Tool cross sectional dimension (H*W)		mm	25*25
Longitudinal feed		mm/r	0.028-6.43
Transverse feed		mm/r	0.028-6.43
Taper of center sleeve inner hole		mm	MT5
Max movement of center sleeve		mm	150
Max transverse movement		mm	±15
Thread	Inch system		72-1/8t/in
	Metric system		0.5-224
	Module		0.5-112
	Diameter pitch		56-1/4DP
Motor specification			7.5kw 1500rpm
Belt specification			B-2260
Dimension (L*W*H)	1000mm	mm	2625*1077*1315
	1500mm	mm	3125*1077*1315
	2000mm	mm	3625*1077*1315
	3000mm	mm	4800*1077*1315
	3500mm	mm

Shenzhen Joint Machinery Co., Ltd. stands as a beacon in the manufacture and export of premium CNC lathe machines, CNC deep hole drilling machines, and Swiss-type automatic lathes, alongside high-performance milling and grinding machines. Our steadfast commitment to excellence ensures delivery of superior machine quality and unrivaled service to a global clientele. By adhering to rigorous quality control processes, we consistently maintain the highest industry standards. Utilizing core technologies from Taiwan and Germany, combined with cutting-edge production equipment and processes, we guarantee exceptional product quality and reliability. Our machines are renowned for their extraordinary precision, stability, and reliability, adept at meeting diverse and high-demand machining requirements. With an expansive global export reach, our products captivate and earn accolades from customers worldwide. Our market presence spans Asia, Europe, South America, North America, and far beyond. We forge enduring partnerships with clients from across the globe, collaboratively creating immense business value.

---
