Basic Info.
Power Type
Series Motor DC
Electric Winch Model
Std9500
Working Voltage of Electric Winch
Low Voltage
Applicable Environment
Mountain Road
Gear Train
3-Stage Planetary
Brake
Automatic, 100% Load Holding
Transport Package
Carton and Wooden Pallet
Specification
9500lbs/4309kgs
Production Capacity
40000/Year
Packaging & Delivery
Package Size
610.00cm * 340.00cm * 260.00cm
Package Gross Weight
38.000kg
Product Description
High quality off-road winches 13500lb with synthetic rope Product Parameters
SPECIFICATION: | |
Rated line pull | 9500lbs/4309kgs single-line |
Motor | 12V DC, Sealed Series Wound 5.2HP |
Gear Train | 3-stage planetary |
Gear Ratio | 216:1/ 150:1 |
Brake | Automatic, 100% load holding |
Clutch | Rotate 90 degrees |
Electrical controls | 400A Sealed Contactor |
Electric cables | Copper 20mm2 |
Wired Controller | 3pin, 12ft(3.7m) |
Wireless Remote | Included |
Rope | Steel Rope: 9.5mm x 26m |
Fairlead | Roller |
Recommended Battery | 650 CCA minimum for winching |
Battery leads | 20mm2, 72ft(1.83m) |
Warranty | 2 years |
Detailed Photos
Packaging & Shipping
Certifications
Company Profile
Zhejiang Towtec Mechanical & Electrical Co.,Ltd is located in the Economic Development Zone of Fenghua, Ningbo. Our factory covers an area of 3000 square meters and our staff all have over 10 years' experiences in winches and off-road field. We are dedicated to designing and manufacturing high quality electric winches, hydraulic winches and 4x4 accessories. Now we have tens of winch models covering capacity from 1,500lb to 20,000lb and hundreds of recovery products.
Our products are widely used in off-road, commercial projects, fire trucks, mili-tary vehicles and other applications. With stable and reliable quality, our products have been exported to the US, Europe, Australia, Southeast Asia, Middle East, Latin America and gained high praise from distributors and off-road enthusiasts.
Our Advantages
1, Reliable and stable quality.
We will spare no efforts to make the winch stronger and durable
2, Quick delivery time.
Sample can be finished in one day. Bulk order delivery time: 7-15 days.
3, Qucik post-sales reponse.
All spare parts in stock for shipping any time.
4, New models are developed every year.
And we can design according to your requirement.
>>
